Question

Page style

  • August 14, 2024
  • 2 replies
  • 414 views

 I want to set this page backround rather than normal white page... i have pdf of this black page... how should i took this background to my document..  want document in this format

    This topic has been closed for replies.

    2 replies

    Bob_Niland
    Community Expert
    Community Expert
    August 14, 2024

    For a simple single-sided document with only one Master Page (Right), and where the dimensions of the background PDF exactly match the page size (which might be A4 here):

    1. View🞃Master Pages
      click anywhere on page outside all text frames
    2. File🞃Import›File… [bgfilename.pdf]
      ⦿ Import By Reference {probably}
    3. Graphics🞃Object Properties…
      verify: Offset From:
      Top [0 cm] Left [0 cm] [Apply]
    4. Graphics🞃Runaround Properties…
      verify ⦿ Don't Run Around [Set]
    5. Graphics🞃Arrange…›Send to Back
    6. View🞃Body Pages
      author at will



    Potential problems

    • The bgfilename.pdf above is presumed to have exactly the same dimensions as the page. If not you have a couple of options for dealing with that, not detailed here.
    • If this is a double-sided document, or has other Master Pages, the graphic needs to be imported to all of them.
    • If this is for a full bleed print workflow, the bgfilename.pdf needs to be larger than the FM page, and will need negative Offset.
    • If performance is sloggy during authoring, unset View🞃Options…
      ☐ Graphics [Set]
      Turn it back on for rendering.
    Known Participant
    August 16, 2024

    Want pdf size match to my page...

    Now pdf is not matching the page dimentions so pdf page is copped its self and try to addjust with a page

     1 st attched pdf i want on my page but result is in on 2nd attched file

    Community Expert
    August 14, 2024

    Hi,

    I do not have FrameMaker here on this laptop. So everything from memory.

    Go to the master page view.

    Insert the PDF not in the header/footer text frames or in the main text frame, but on the white area outside of any text frame. Then position the graphics file, so that it covers the whole page. You can use the object properties to adjust the position. Or use the mouse.

    Best regards, Winfried

    Known Participant
    August 14, 2024

    Can you please explain in detail or step by setp



    Community Expert
    August 14, 2024

    I do not have access to FrameMasker until next week. Therefore I cannot give you all details.

    In the View menu with one of the last options in this list you can switch to the master page view.

    Usually there is a main text frame which has a tag like A, B, C. When you switch to the body page view (after you have added your background PDF), you will type your content into this text frame.

    Most often small background text frames for the header and the footer. In these text frames you can enter text only on the master page.

    Click somewhere outside of any text frame in the page margin and click File > Import > File. Select your background PDF and click OK.

    Here is the link to the online help:

    https://help.adobe.com/en_US/framemaker/using/using-framemaker/FrameMaker-2022/user-guide/frm_text_tx-importing-and-linking_import-graphics.html?rhhlterm=insert%20graphics&rhsyns=%20#topic_import-graphics__section_import-a-graphic
