Help with excel-to-Illustrator fonts in charts

I've seen posts about this before, but haven't found anything that's fixed it for me. I'm runing OSX 10.15.3, trying to paste copied graphs from Excel (version 16.34) into Illustrator 24.0.3. Whatever font I've used to make a graph in Excel, when I paste it into Illustrator, the text changes from letters to symbols (screenshot below).



I tried a solution I've seen elsewhere, exporting from Excel to a PDF. When I open the PDF in Acrobat, it looks fine, but when I open it in Illustrator, it looks just like in the screenshot below. If I export from Excel into a postscript file, Illustrator opens it and it looks normal. That isn't a great work-around, however, because the imported text isn't in text boxes, so it doesn't make it any easier to edit than the other way.



Any thoughts? Why is Illustrator not reading the font the same way that Acrobat and Excel are?



Thanks in advance.


    This topic is closed to new replies. Start a new post to keep the conversation going.
    Brad @ Roaring Mouse
    Brad @ Roaring MouseCorrect answer
    Community Expert
    Sep 21, 2021 12:12 AM UTC

    This is an old thread, but in case others have issues, the reason the PDF creates "gibberish" is that Excel subsets the fonts for the purposes of display/printing ONLY, so the encoding is created on the fly for each instance of a subset for that purpose only. (It's particularly a problem with expanded character sets in fonts like Calibri), so when it's opened in Illustrator, there's no order at all to it that it can understand. The best option is to export as SVG instead.

    View reply

    20 replies

    Scrambledeggs
    Participating Frequently
    Nov 4, 2024 9:00 PM UTC

    Select the chart in Excel and change the font to Avenir.

    Copy and paste to Illustrator.

    Translate
    Brad @ Roaring Mouse
    Community Expert
    Brad @ Roaring MouseCommunity ExpertCorrect answer
    Community Expert
    Sep 21, 2021 12:12 AM UTC

    This is an old thread, but in case others have issues, the reason the PDF creates "gibberish" is that Excel subsets the fonts for the purposes of display/printing ONLY, so the encoding is created on the fly for each instance of a subset for that purpose only. (It's particularly a problem with expanded character sets in fonts like Calibri), so when it's opened in Illustrator, there's no order at all to it that it can understand. The best option is to export as SVG instead.

    Translate
      ellenv54463183
      Participating Frequently
      Mar 24, 2022 8:57 AM UTC

      Export to SVG is a great solution!

      Translate
      Gia Ninja
      Gia Ninja
      Participating Frequently
      Jul 29, 2020 11:32 PM UTC

      Brilliant, thank you, changing the font to Avenir works. That has been annoying me so much. This is a time saver. Thank you.

      Translate
        Stijn_S
        Participant
        Apr 16, 2020 9:34 AM UTC

        Hi,
        I see your problem is solved, but it might be interesting to mention there is another way to approach this: make you charts in Illustrator using the Datylon Graph plug-in. Just upload or copy the data from Excel, not the graph itself, and build the graph in Illustrator with numerous styling options and using all the fonts you like. You can also create templates which allow you to re-use your charts by simply uploading new data.
        See datylon.com/graph.

        Translate
        Diane T-H
        Participant
        Apr 6, 2020 4:38 PM UTC

        Hi, I've been frustrated by this for a long time, but this is the first time I have checked online to see if there was a solution. My workaround has been to convert all fonts in the graph manually to Avenir Next, an OpenType font. Not sure if other OpenType fonts would work. This is readable when I copy and paste the graph to Illustrator. I'm using Illustrator 2020 on a MacBook pro2017 running Catalina, and the most recent version of Excel, whatever that is. But I've had this problem for at least a year, under several other operating systems and versions of Illustrator and Excel.

        Translate
          Derek14051Author
          Known Participant
          Apr 6, 2020 4:43 PM UTC

          Do you convert to that font in Excel, or after copying into Illustrator?

          Translate
          Diane T-H
          Participant
          Apr 6, 2020 5:08 PM UTC

          I do it in Excel, in the graph. It's tedious, especially if I have a bunch of graphs to spruce up for publication. I'd love to find a more efficient way.

          Translate
          Monika Gause
          Community Expert
          Monika GauseCommunity Expert
          Community Expert
          Mar 4, 2020 4:33 PM UTC

          Use a different font than Calibri

          Translate
            Derek14051Author
            Known Participant
            Mar 4, 2020 5:38 PM UTC

            I tried Arial, Times, and a few others. No luck.

            Translate
              Larry G. Schneider
              Community Expert
              Larry G. SchneiderCommunity Expert
              Community Expert
              Mar 4, 2020 5:53 PM UTC

              You will have to change the font in Excel before making the PDF or copy/pasting the chart into Illustrator. Is that what you tried or did you try changing the font in AI after the fact?

              Translate
              Mylenium
              Mylenium
              Legend
              Mar 4, 2020 3:59 PM UTC

              Well, the magic of Unicode and OpenType fonts. This typically happens when there is a language mismatch, i.e. the region and language system settings don't line up with the app languages. Start by checking that. In fact I'm pretty sure that if you checked your PDFs you might already find hints at potentially wrong font sub-sets being embedded. The only reason it may work with Postscript is that it gets dumbed down to the standard Western/ Latin encoding on export.



              Mylenium

              Translate
              Derek14051Author
              Known Participant
              Mar 4, 2020 5:37 PM UTC

              I was hopeful when I read this, but checked the language settings in Excel and they're set to US English...is there a language setting in Illustrator that I can fix? I couldn't find anything.

              Translate
