Is it possible to get Object Position updates while dragging an object in Illustrator?

I'm trying to find if there is a way to get position data from an object while it's being dragged / repositioned by the user, but I'm not finding a way to get values updated until after the drop has completed.





For context, I've tried events with AIHostAdapter as well as native events in the C++ SDK directly, but neither seem to have any events for dragging position updates, their events only seem to be before and after dragging objects, so I'm resorting to polling.



Currently I can poll an object's left/top position during dragging, however the results are the original position until the drag is completed, it's only updated after drop.



Have tried polling:





app.activeDocument.selection[0].left;
app.activeDocument.selection[0].top;




As well as:
app.activeDocument.selection[0].geometricBounds[0];
app.activeDocument.selection[0].geometricBounds[1];

But neither seem to update until after the drag is complete.
This topic is closed to new replies. Start a new post to keep the conversation going.

24 replies

Kurt Gold
Community Expert
Community Expert
Dec 18, 2024 8:17 PM UTC

Perhaps I'm overlooking something about your request, but Illustrator's built-in Info panel does provide that live info while dragging objects (based on mouse cursor position).



Wouldn't that suit your purpose?

Translate
Justin Taylor-Hyper Brew
Community Expert
Community Expert
Dec 18, 2024 8:37 PM UTC

Yes the Info panel's X/Y/W/H values do update in realtime. Do you know of a way to access them via the API?

Translate
Kurt Gold
Community Expert
Community Expert
Dec 18, 2024 9:00 PM UTC

No, unfortunately I don't know that.

Translate
Legend
Dec 18, 2024 1:17 AM UTC

I am not familiar with it, so I can't help you. However, note that such a large number of property accesses in Illustrator's ExtendScript will cause “MRAP” error and Illustrator will freeze, so this is not a good direction to go on.



The “Annotator” in the Illustrator SDK may be close.

Translate
Justin Taylor-Hyper Brew
Community Expert
Community Expert
Dec 18, 2024 7:12 PM UTC

Thank you! I checked out the Annotator sample and while it has some promising features like real-time position updates for the mouse and objects with Mouse Drag events and such, it looks like this info is only available to the plugin if the user has your custom tool selected, not by using a default  tool like the Selection tool.



Does that limitation sound correct or are you aware of any ways to get MouseDrag info on the built-in tools?

Translate
Legend
Dec 19, 2024 1:16 AM UTC

It depends on what you want to create, but it seems sufficient to me to get start and end positions, because often I combine many such events into one by debouncing them.

Translate
m1b
Community Expert
Community Expert
Dec 18, 2024 1:12 AM UTC

@Dirk Becker any ideas?

Translate
Legend
Dec 19, 2024 6:06 AM UTC

Sorry. My only Illustrator plug-in implements an own font+text scripting similar to InDesign's, and works around the worst ScriptUI oddities (that BridgeTalk thing). I have not even touched any kind of notifications beyond my menu item.

Translate
m1b
Community Expert
Community Expert
Dec 19, 2024 6:13 AM UTC

No worries Dirk, thanks for replying. 🙂
