Word Art maybe...

  • March 20, 2022
  • 2 replies
  • 283 views

I am new to using Illustrator so I'm trying to figure things out as I go. I'm creating a slide in picture frame with the word MiMi at the bottom. I want the word to be connected to the bottom of the picture window but still connected to the frame. I will cut this out using a laser. Any help would be appreciated.

 

    This topic has been closed for replies.

    2 replies

    Brad @ Roaring Mouse
    Community Expert
    Brad @ Roaring MouseCommunity Expert
    Community Expert
    March 21, 2022

    Easiest would be to create your word MiMi in the font you want. Convert it to Outlines. If any of your letters overlap, use the Pathfinder panel to Unite them into one shape. Draw your rectangle and send it behind your type (Object > Arrange > Send to Back).

    Move your type to align how you like it at the bottom of the rectangle. Then select both the type and the rectangle and use the Pathfinder panel to apply the Minus Front effect. This should subtract the type (which is in front) out of the rectangle (behind), leaving you with the shape the way you want. Apply whatever stroke you want!

    Jacob Bugge
    Community Expert
    Jacob BuggeCommunity Expert
    Community Expert
    March 20, 2022

    Martin,



    As I (mis)understand it, you can use the Shape Builder, when you have abutment/overlap between parts,



    You can have a look here and/or here:

    https://helpx.adobe.com/illustrator/using/creating-shapes-shape-builder-tool.html
    https://helpx.adobe.com/illustrator/atv/cs5-tutorials/creating-complex-art-with-the-shape-builder-tool.html
