converting CMYK image to multichannel (black + one spot color)

Question

I guess my first question is this: Can I attach a .PSD file to this question? Or just an image?

Here's my issue: I'm doing the design for a literary magazine's anniversary issue and have never been formally trained. Here's my panic: We started out thinking this book would be four color and therefore used CMYK color profile. But now it's black with one spot color, so I have to convert all the images to Multichannel mode and, according to the printer, I should have two channels only: black and the pantone spot color (in this case, Pantone Warm Red C).

So here's the favor I'm asking for: Can someone give me the basic 1-2-3 steps they would to follow to change the PSD file for this image from CMYK to Multichannel black + Pantone Warm Red C? I'm having so much trouble with this. I've been researching and experimenting, but I'm quite confused about layers, transparency, overlays, all that. The CMYK color mode file has two layers: a vector silhouette (the woman) with an image overlay (the pattern fill). I know how to change to multichannel mode, and I'm able to add a new spot channel, but it just isn't working right. When the layers all merge together, I'm stuck with either a solid red background and don't know how to make it be an overlay over the vector silhouette or it won't show the red at all. Either way, and I lose the transparency, even when I save the file as DCS 2.0. I asked the printer for guidance several days ago, but they haven't responded.

I know it's the day before Thanksgiving, but if someone could just give me the steps they would follow to change this CMYK file to a multichannel file with black + one spot color and still maintain the transparency, overlay, etc., I'd be most grateful. Basically, how do I make it look like this original image using only two channels?

I'm really stuck here, much thanks. I'll attach the .PSD file, too, if someone can tell me how -- didn't see an option for that in the toolbar.

Stephen Marsh · Accepted Answer

The time and effort you've already put into this is an astounding kindness, and I am so thankful. And guess what? The saturated version did the trick!! I have about 45 images I have to alter and it's been a disaster of a day but you've turned it around. (And thank goodness you're in Australia and helping people on these forums, not busy stuffing a turkey for Thanksgiving in the US!)

You're a good person. Thank you a million times over for your help!

Just in case I remove the actions in the future and somebody else requires a similar solution, I’ll very briefly document two different methods of turning a CMYK image to 2 spot colours.

In this case, the images were “mostly” red and black/brown in content. This naturally lends itself to using the M and the K channels (M = Spot Red and K = Black), discarding the cyan and yellow. There will not always be a perfect solution to mapping or converting the full range of CMYK colours/tones into 2 colours, so expectations may need to be adjusted.

Another method was a little more convoluted, however variations on this approach have been useful in the past and have resulted in similar separations to those created by the old “Powertone” extended dutotone separation plug-in that was discontinued a long while ago…

Create a history snapshot to revert back to
Convert to Lab colour mode
Copy the “a” channel (which holds the opposing magentary-red/green hues)
Select the history snapshot to return back to the original CMYK version
Create a new channel and paste the clipboard “a” channel data into this alpha channel
Apply image the alpha channel to itself, invert on, difference blend mode, preserve transparency, OK
Invert the result
Apply curves/levels as needed to adjust the tones darker at the shadows or elsewhere
Convert to multichannel mode
Delete the cyan, magenta and yellow channels
Target the black channel and convert to grayscale mode
Double click on the alpha channel and change to a spot colour channel and assign a Pantone colour
Select the black channel
Apply image the black channel to itself in linear burn blend mode 100% opacity, preserve transparency
Select the spot red chnnel
Apply image the red channel to itself in multiply blend mode 100% opacity, preserve transparency
Adjust the tones of each channel with curves/levels where necessary

Stephen Marsh · Answer

The forum software changed the file to a JPEG (but still CMYK). You would need to upload the original PSD to say DropBox or another file sharing service.

Are all of the images similar to the one attached? Often conversions are image dependent, what works for one image may not work for another.

Make sure to keep the CMYK originals and work on duplicated files so that you can recover if things go wrong.

I’ll post a link where you can download an action (no guarantee or warranty provided/implied, use at your own risk)… The Photoshop preview is not very accurate, so the print result may or may not be anything like the “softproof”.

Attached is a “preview” of a 2 channel conversion, the original was multichannel however this is in CMYK mode, still 2 channel with a “faux preview ICC profile”…
