Hi,
I have been given a lable to draw for a sticker. I have been given the arc radiues but I'm unsure how to input this value to create the art? Thank you!
figure out what units that drawing is supposed to represent (because there are no units there)...
Then grab your circle tool and click on the drawing area. In the dialog that opens, input 1030pt into the "width" and "height" fields. then click ok. now you have a circle with a radius of 515pt (use whatever unit you want.. pixels are the same as points.. you can also input other units like mm, inches, etc.
then select that circle, and go to the Object menu, and select Path > Offset Path. Then
...Copy link to clipboard
Copied
Hi,
I have been given a label to draw for a sticker. I have been given the arc radius's but I'm unsure how to input this value to create the art? Thank you!
Copy link to clipboard
Copied
figure out what units that drawing is supposed to represent (because there are no units there)...
Then grab your circle tool and click on the drawing area. In the dialog that opens, input 1030pt into the "width" and "height" fields. then click ok. now you have a circle with a radius of 515pt (use whatever unit you want.. pixels are the same as points.. you can also input other units like mm, inches, etc.
then select that circle, and go to the Object menu, and select Path > Offset Path. Then enter 65 [units] into the dialog and click ok. Now you'll have two circles with radii that match the scale of the drawing. then you just need to figure out the width and trim the rest of the circles.
Copy link to clipboard
Copied
Thanks so much! I really apprectiate this! The units are mm.
Copy link to clipboard
Copied
Kandice,
In addition to what Dilliam said, I believe you need a clarification about the sides of the label:
Are they really meant to be parallel, as in drawing an Arch for a flat or cylindrical object with a more curved bottom, or directed towards the centre of the circle(s), as in drawing an Arc for a normal conical object (icecream cone rather than bottleneck)?
In either case, the horizontal distance between the sides at top/larger circle is 179.2785, in other words quite close to the 180. You can use 180 (or 179) for the width.
For the given (unknown) unit, you can proceed as follows to create the label with artwork in one go:
For a normal Arch (without the more curved bottom, which you can apply afterwards, if you must, otherwise you need a customized way which will alsi look funny (maybe both hah hah and peculiar)), you can create a rectangle that is 180 (or 179) wide and 65 tall, then use that as the boundary for the label with or without a stroke, then create the artwork unbent, then Group and apply Arch with a Bend of 10%.
For an Arc, you can create a rectangle that is 160 (or 159) wide and 65 tall, then use that as the boundary for the label with or without a stroke, then create the artwork unbent, then Group and apply Arc with a Bend of 10%.
Copy link to clipboard
Copied
Thanks so much I really appreciate this. The units are mm! But I think I can figure it out based on all the help I have received on this post. Forever grateful!
Copy link to clipboard
Copied
For my part you are welcome, Kandice.
I have assumed that you need to create both the label and the artwork bent to match and fit.
Hence the ways to do everything in one go, with everything bent in one and the same transformation, either Warp>Arch or Warp>Arc, my guess being the latter.
Copy link to clipboard
Copied
Copy link to clipboard
Copied
Bored, me? No...
Copy link to clipboard
Copied
for some reason i have a strong urge to automate the drawing of that diagram... But i can't think of a reasonable use case for a function that draws that. =(
Copy link to clipboard
Copied
came back to say this is awesome. and thorough. and awesome.
it's ok to do stuff like that. you don't need to be bored to justify finding enjoyment in doing some mental exercise in pursuit of helping a fellow human. You never see someone paddling a canoe and saying "what? i was bored". Because we accept paddling a canoe as a standard hobby. I think the world would be better off if more people viewed solving technical problems and creating clean and easy to read representations of the solution as a hobby.
This drawing is just as much "art" as most any art i see. It's art and math together, and that's beautiful. So don't ever feel like you owe some kind of explanation for why you spent time to make it. Even if you were just kidding. I want to reinforce the message for everyone. Things like this are good practice for your brain and your technical skills and we would all benefit from doing exercises like this, especially in this shared environment.
Copy link to clipboard
Copied
thanks mate. I'm now going to spray paint this on a wall somewhere...
Copy link to clipboard
Copied
i think a tattoo would demonstrate more commitment on your part.
how committed are you?
Copy link to clipboard
Copied
not very... actually, let's drop the very...
Copy link to clipboard
Copied
Thanks so much! I really apprectiate this!
