illustrator script to Renumber/Reorder the Artboards with there position

Since Illustrator has a limit of 1000 artboards, this script will not work if the document contains more than 500 artboards

I changed the algorithm for applying sorted melons so that it would not create a duplicate of all elements, and the insertion would be pointwise. Thus, the limit of the updated script is not 500 but 999 artboards

Also the sorting method from Settings was not taken into account, this has been fixed.

/*

    Sort Artboards
    for Adobe Illustrator

    by m1b
    here: https://community.adobe.com/t5/illustrator-discussions/randomly-order-artboards/m-p/12692397
    and: https://community.adobe.com/t5/illustrator-discussions/illustrator-script-to-renumber-reorder-the-artboards-with-there-position/m-p/12752568

    Sorting by position compares top or left or right values to n decimal places, 3 by default
    (without this limit, tiny discrepancies come in to play and cause weird results)

    2023.11.15 Andrew_BJ:
    - Fixed limit of 500 artboards to sort. Now limit is 999 (Limit 1000 by AI - 1)
    - Fixed setup UI by selected sorting method in settings object

*/

var SortMethod = {
    NAME: { sorter: sortByName, displayName: 'By Name' },
    POSITION_TOP_LEFT: { sorter: sortByPositionTopLeft, displayName: 'By Position Top Left' },
    POSITION_TOP_RIGHT: { sorter: sortByPositionTopRight, displayName: 'By Position Top Right' },
    POSITION_LEFT_TOP: { sorter: sortByPositionLeftTop, displayName: 'By Position Left Top' },
    POSITION_RIGHT_TOP: { sorter: sortByPositionRightTop, displayName: 'By Position Right Top' },
    REVERSE: { sorter: reverse, displayName: 'Reverse' },
    SHUFFLE: { sorter: shuffle, displayName: 'Shuffle' },
};

var settings = {
    action: sortArtboards,
    sortMethod: SortMethod.POSITION_TOP_LEFT,
    decimalPlaces: 3,
    showUI: true
};


main();

function main() {

    if (settings.showUI) {
        invokeUI();

    } else {
        settings.action.apply(null, [app.activeDocument, settings.sortMethod.sorter]);
    }
}


function sortArtboards(doc, sortFunction) {

    var decimalPlaces = Math.pow(10, settings.decimalPlaces);

    // make an array of existing artboards
    var _artboards = [];
    for (var i = 0; i < doc.artboards.length; i++)
    {
        var a = doc.artboards[i];
        var s = {name: a.name, artboardRect: a.artboardRect, srcIndex: i};

        _artboards.push(s);
    }

    // sort
    sortFunction(_artboards, decimalPlaces);

    // add the artboards and match to existing
    for (var i = 0; i < _artboards.length; i++)
    {
        var s = _artboards[i];

        var a = doc.artboards[s.srcIndex];
        var b = doc.artboards.add(a.artboardRect);
        b.name = a.name;
        b.rulerOrigin = a.rulerOrigin;
        b.rulerPAR = a.rulerPAR;
        b.showCenter = a.showCenter;
        b.showCrossHairs = a.showCrossHairs;
        b.showSafeAreas = a.showSafeAreas;
        a.remove();
        for (var j = i + 1; j < _artboards.length; j++)
            if (_artboards[j].srcIndex > s.srcIndex)
                _artboards[j].srcIndex--;
    }
}

// Sorting Functions

function reverse(_artboards) {
    _artboards.reverse();
}

function sortByName(_artboards) {
    _artboards.sort(function (a, b) {
        if (a.name < b.name) return -1;
        if (a.name > b.name) return 1;
        return 0;
    });
}

function sortByPositionTopLeft(_artboards, decimalPlaces) {
    // sorts T < B L < R
    decimalPlaces = decimalPlaces || 1000;
    _artboards.sort(function (a, b) {
        return (
            Math.round((b.artboardRect[1] - a.artboardRect[1]) * decimalPlaces) / decimalPlaces
            || Math.round((a.artboardRect[0] - b.artboardRect[0]) * decimalPlaces) / decimalPlaces
        )
    });
}

function sortByPositionTopRight(_artboards, decimalPlaces) {
    // sorts T < B, R < L
    _artboards.sort(function (a, b) {
        return (
            Math.round((b.artboardRect[1] - a.artboardRect[1]) * decimalPlaces) / decimalPlaces
            || Math.round((b.artboardRect[0] - a.artboardRect[0]) * decimalPlaces) / decimalPlaces
        )
    });
}

function sortByPositionLeftTop(_artboards, decimalPlaces) {
    // sorts L < R, T < B
    _artboards.sort(function (a, b) {
        return (
            Math.round((a.artboardRect[0] - b.artboardRect[0]) * decimalPlaces) / decimalPlaces
            || Math.round((b.artboardRect[1] - a.artboardRect[1]) * decimalPlaces) / decimalPlaces
        )
    });
}

function sortByPositionRightTop(_artboards, decimalPlaces) {
    // sorts R < L, T < B
    _artboards.sort(function (a, b) {
        return (
            Math.round((b.artboardRect[0] - a.artboardRect[0]) * decimalPlaces) / decimalPlaces
            || Math.round((b.artboardRect[1] - a.artboardRect[1]) * decimalPlaces) / decimalPlaces
        )
    });
}

function shuffle(_artboards) {
    var i = _artboards.length,
        j,
        temp;
    while (i--) {
        j = Math.floor(Math.random() * (i + 1));
        // swap randomly chosen element with current element
        temp = _artboards[i];
        _artboards[i] = _artboards[j];
        _artboards[j] = temp;
    }
}


function invokeUI(p) {

    // add the sort methods to array
    var sortMethods = [];
    for (var i = 0; i < SortMethod.reflect.properties.length; i++)
        if (SortMethod.hasOwnProperty(SortMethod.reflect.properties[i]))
            sortMethods.push(SortMethod[SortMethod.reflect.properties[i]]);

    // show UI
    var dialog = makeUI(p)
    dialog.center();
    var result = dialog.show();
    dialog = null;

    // handle result
    if (result === -1) {
        // cancelled
        return;

    } else if (result === 1) {
        // do action
        return;
        settings.action.apply(null, [app.activeDocument, settings.sortMethod.sorter]);
    }

    function makeUI(p) {
        var w = new Window("dialog", 'Sort Artboards'),
            menuRow = w.add("Group {orientation:'row', alignment:['fill','top']}"),
            // stack = w.add("Group {orientation:'stack', alignment:['fill','fill']}"),
            buttonRow = w.add("Group {orientation:'row', alignment:['right','top']}");
        menuRow.add("statictext", undefined, "Sort Method");
        var mainMenu = menuRow.add("Dropdownlist {alignment:['left','center']}"),
            cancelButton = buttonRow.add('button', undefined, 'Cancel', { name: 'cancel' }),
            okButton = buttonRow.add('button', undefined, 'Sort', { name: 'ok' });

        // add the sort methods to menu
        var select = 0;
        for (var i = 0; i < sortMethods.length; i++)
        {
            mainMenu.add('item', sortMethods[i].displayName);
            if (settings.sortMethod.displayName == sortMethods[i].displayName)
                select = i;
        }

        mainMenu.preferredSize.width = 180;
        alert(settings.sortMethod.displayName);
        mainMenu.selection = mainMenu.items[select];
        updateUI();

        okButton.onClick = okButtonClicked;
        cancelButton.onClick = cancelButtonClicked;
        // mainMenu.onChange = updateUI;


        return w;

        function okButtonClicked() {
            alert(mainMenu.selection.index);
            settings.sortMethod = sortMethods[mainMenu.selection.index];
            w.close(1);
        };

        function cancelButtonClicked() {
            w.close(-1);
        }

        function updateUI() {
            // var s = mainMenu.selection ? mainMenu.selection.index : 0;
        }
    }
}

No, because the rearrange artboards it order the artboards by their number, not their position.
