Masking Error

[lockca]

When selecting background or subject under the masking tool I get an error "something went wrong, there was an unexpected error and your request could not be completed"  This only started last night.  I have searched down through conversations but haven't found anything to correct it.  I tried to upate my drivers however it says you have the latest drivers installed.  Can someone please help me with this error.  Here are my system info

Lightroom Classic version: 12.2.1 [ 202303011008-5bfbce17 ]
License: Creative Cloud
Language setting: en
Operating system: Windows 10 - Home Premium Edition
Version: 10.0.22621
Application architecture: x64
System architecture: x64
Logical processor count: 12
Processor speed: 2.0GHz
SqLite Version: 3.36.0
CPU Utilisation: 0.0%
Built-in memory: 15721.1 MB
Dedicated GPU memory used by Lightroom: 3737.2MB / 495.5MB (754%)
Real memory available to Lightroom: 15721.1 MB
Real memory used by Lightroom: 649.3 MB (4.1%)
Virtual memory used by Lightroom: 9136.4 MB
GDI objects count: 941
USER objects count: 3063
Process handles count: 2462
Memory cache size: 0.0MB
Internal Camera Raw version: 15.2 [ 1381 ]
Maximum thread count used by Camera Raw: 5
Camera Raw SIMD optimization: SSE2,AVX,AVX2
Camera Raw virtual memory: 1980MB / 7860MB (25%)
Camera Raw real memory: 2364MB / 15721MB (15%)
System DPI setting: 96 DPI
Desktop composition enabled: Yes
Standard Preview Size: 1920 pixels
Displays: 1) 1920x1080, 2) 1920x1080
Input types: Multitouch: No, Integrated touch: No, Integrated pen: No, External touch: No, External pen: No, Keyboard: No

Graphics Processor Info:
DirectX: AMD Radeon(TM) Graphics (31.0.12044.3)
Init State: GPU for Image Processing supported by default with custom export support
User Preference: Auto

Application folder: C:\Program Files\Adobe\Adobe Lightroom Classic
Library Path: C:\Users\lockc\OneDrive\Pictures\Lightroom\Lightroom Catalog.lrcat
Settings Folder: C:\Users\lockc\AppData\Roaming\Adobe\Lightroom

Installed Plugins:
1) AdobeStock
2) Flickr
3) Nikon Tether Plugin

Config.lua flags: None

Adapter #1: Vendor : 1002
Device : 164c
Subsystem : 8924103c
Revision : c2
Video Memory : 495
Adapter #2: Vendor : 1414
Device : 8c
Subsystem : 0
Revision : 0
Video Memory : 0
AudioDeviceIOBlockSize: 1024
AudioDeviceName: $$$/dvaaudiodevice/SystemDefaultAndEffectiveDeviceName=System Default - Headphone (Realtek(R) Audio)#{comment}DVAAU-4201250: Open the audio hardware preferences page.
AudioDeviceNumberOfChannels: 2
AudioDeviceSampleRate: 48000
Build: LR5x19
Direct2DEnabled: false
GL_ACCUM_ALPHA_BITS: 8
GL_ACCUM_BLUE_BITS: 8
GL_ACCUM_GREEN_BITS: 8
GL_ACCUM_RED_BITS: 8
GL_ALPHA_BITS: 8
GL_BLUE_BITS: 8
GL_DEPTH_BITS: 32
GL_GREEN_BITS: 8
GL_MAX_3D_TEXTURE_SIZE: 2048
GL_MAX_TEXTURE_SIZE: 16384
GL_MAX_TEXTURE_UNITS: 8
GL_MAX_VIEWPORT_DIMS: 16384,16384
GL_RED_BITS: 8
GL_RENDERER: AMD Radeon(TM) Graphics
GL_SHADING_LANGUAGE_VERSION: 4.60
GL_STENCIL_BITS: 8
GL_VENDOR: ATI Technologies Inc.
GL_VERSION: 4.6.0 Compatibility Profile Context 22.20.44.221025
GPUDeviceEnabled: false
OGLEnabled: true
GL_EXTENSIONS: GL_EXT_abgr GL_EXT_blend_color GL_EXT_blend_minmax GL_EXT_blend_subtract GL_EXT_texture_object GL_EXT_vertex_array GL_EXT_compiled_vertex_array GL_EXT_texture3D GL_EXT_bgra GL_EXT_draw_range_elements GL_EXT_point_parameters GL_EXT_texture_edge_clamp GL_ARB_multitexture GL_ARB_multisample GL_ARB_texture_cube_map GL_ARB_texture_env_add GL_ARB_transpose_matrix GL_EXT_blend_func_separate GL_EXT_fog_coord GL_EXT_multi_draw_arrays GL_EXT_secondary_color GL_EXT_texture_env_add GL_EXT_texture_filter_anisotropic GL_EXT_texture_lod GL_EXT_texture_lod_bias GL_NV_blend_square WGL_EXT_swap_control GL_ARB_point_parameters GL_ARB_texture_border_clamp GL_ARB_texture_compression GL_EXT_texture_compression_s3tc GL_EXT_texture_env_combine GL_EXT_texture_env_dot3 GL_ARB_shadow GL_ARB_shadow_ambient GL_ARB_texture_env_combine GL_ARB_texture_env_dot3 GL_ARB_depth_texture GL_ARB_fragment_program GL_ARB_vertex_program GL_ARB_window_pos GL_ATI_draw_buffers GL_ATI_texture_env_combine3 GL_EXT_shadow_funcs GL_EXT_stencil_wrap GL_EXT_texture_rectangle GL_NV_primitive_restart GL_S3_s3tc GL_ARB_fragment_program_shadow GL_ARB_fragment_shader GL_ARB_occlusion_query GL_ARB_point_sprite GL_ARB_shader_objects GL_ARB_shading_language_100 GL_ARB_texture_non_power_of_two GL_ARB_vertex_buffer_object GL_ARB_vertex_shader GL_EXT_blend_equation_separate GL_EXT_depth_bounds_test GL_ARB_color_buffer_float GL_ARB_draw_buffers GL_ARB_half_float_pixel GL_ARB_pixel_buffer_object GL_ARB_texture_float GL_ARB_texture_rectangle GL_EXT_framebuffer_object GL_EXT_pixel_buffer_object GL_OES_draw_texture GL_EXT_framebuffer_blit GL_EXT_framebuffer_multisample GL_EXT_packed_depth_stencil GL_EXT_texture_format_BGRA8888 GL_ATI_separate_stencil GL_ATI_shader_texture_lod GL_EXT_draw_buffers2 GL_EXT_framebuffer_sRGB GL_EXT_geometry_shader4 GL_EXT_gpu_program_parameters GL_EXT_gpu_shader4 GL_EXT_texture_array GL_EXT_texture_buffer_object GL_EXT_texture_compression_latc GL_EXT_texture_compression_rgtc GL_EXT_texture_integer GL_EXT_transform_feedback GL_NV_depth_buffer_float GL_OES_EGL_image GL_EXT_provoking_vertex GL_EXT_texture_sRGB GL_EXT_texture_shared_exponent GL_ARB_depth_buffer_float GL_ARB_draw_instanced GL_ARB_framebuffer_object GL_ARB_framebuffer_sRGB GL_ARB_geometry_shader4 GL_ARB_half_float_vertex GL_ARB_instanced_arrays GL_ARB_map_buffer_range GL_ARB_texture_buffer_object GL_ARB_texture_compression_rgtc GL_ARB_texture_rg GL_ARB_transform_feedback GL_ARB_vertex_array_object GL_EXT_direct_state_access GL_EXT_texture_snorm GL_ARB_compatibility GL_ARB_copy_buffer GL_ARB_depth_clamp GL_ARB_draw_buffers_blend GL_ARB_draw_elements_base_vertex GL_ARB_fragment_coord_conventions GL_ARB_sample_shading GL_ARB_seamless_cube_map GL_ARB_shader_texture_lod GL_ARB_sync GL_ARB_texture_cube_map_array GL_ARB_texture_gather GL_ARB_texture_multisample GL_ARB_texture_multisample_no_array GL_ARB_uniform_buffer_object GL_ATI_meminfo GL_EXT_texture_storage GL_NV_copy_image GL_NV_texture_barrier GL_AMD_blend_minmax_factor GL_AMD_depth_clamp_separate GL_AMD_sample_positions GL_ARB_ES2_compatibility GL_ARB_base_instance GL_ARB_blend_func_extended GL_ARB_debug_output GL_ARB_draw_indirect GL_ARB_explicit_attrib_location GL_ARB_get_program_binary GL_ARB_gpu_shader5 GL_ARB_gpu_shader_fp64 GL_ARB_occlusion_query2 GL_ARB_robustness GL_ARB_sampler_objects GL_ARB_separate_shader_objects GL_ARB_shader_bit_encoding GL_ARB_shader_precision GL_ARB_shader_stencil_export GL_ARB_shader_subroutine GL_ARB_tessellation_shader GL_ARB_texture_compression_bptc GL_ARB_texture_rgb10_a2ui GL_ARB_texture_swizzle GL_ARB_timer_query GL_ARB_transform_feedback2 GL_ARB_transform_feedback3 GL_ARB_vertex_attrib_64bit GL_ARB_viewport_array GL_EXT_shader_image_load_store GL_EXT_texture_sRGB_decode GL_AMD_bus_addressable_memory GL_AMD_pinned_memory GL_ARB_conservative_depth GL_ARB_internalformat_query GL_ARB_shader_atomic_counters GL_ARB_shader_image_load_store GL_ARB_shading_language_420pack GL_ARB_texture_storage GL_ARB_transform_feedback_instanced GL_EXT_color_buffer_half_float GL_EXT_debug_label GL_AMD_shader_trinary_minmax GL_ARB_ES3_compatibility GL_ARB_arrays_of_arrays GL_ARB_clear_buffer_object GL_ARB_compute_shader GL_ARB_copy_image GL_ARB_explicit_uniform_location GL_ARB_fragment_layer_viewport GL_ARB_framebuffer_no_attachments GL_ARB_internalformat_query2 GL_ARB_invalidate_subdata GL_ARB_multi_draw_indirect GL_ARB_program_interface_query GL_ARB_shader_image_size GL_ARB_shader_storage_buffer_object GL_ARB_stencil_texturing GL_ARB_texture_buffer_range GL_ARB_texture_storage_multisample GL_ARB_texture_view GL_ARB_vertex_attrib_binding GL_EXT_copy_buffer GL_KHR_debug GL_AMD_gpu_shader_half_float GL_AMD_gpu_shader_int64 GL_ARB_bindless_texture GL_ARB_buffer_storage GL_ARB_clear_texture GL_ARB_enhanced_layouts GL_ARB_indirect_parameters GL_ARB_multi_bind GL_ARB_query_buffer_object GL_ARB_shader_draw_parameters GL_ARB_shader_group_vote GL_ARB_sparse_texture GL_ARB_texture_stencil8 GL_EXT_copy_image GL_EXT_draw_buffers_indexed GL_EXT_geometry_point_size GL_EXT_gpu_shader5 GL_EXT_sRGB_write_control GL_EXT_shader_integer_mix GL_EXT_shader_io_blocks GL_EXT_tessellation_point_size GL_EXT_tessellation_shader GL_EXT_texture_border_clamp GL_EXT_texture_buffer GL_EXT_timer_query GL_KHR_blend_equation_advanced GL_KHR_blend_equation_advanced_coherent GL_NV_shader_atomic_int64 GL_ARB_clip_control GL_ARB_conditional_render_inverted GL_ARB_cull_distance GL_ARB_derivative_control GL_ARB_direct_state_access GL_ARB_get_texture_sub_image GL_ARB_pipeline_statistics_query GL_ARB_shader_texture_image_samples GL_ARB_sparse_buffer GL_ARB_texture_barrier GL_ARB_transform_feedback_overflow_query GL_EXT_polygon_offset_clamp GL_EXT_render_snorm GL_KHR_robust_buffer_access_behavior GL_KHR_robustness GL_OVR_multiview GL_ARB_gpu_shader_int64 GL_ARB_parallel_shader_compile GL_ARB_shader_ballot GL_ARB_shader_clock GL_ARB_shader_viewport_layer_array GL_ARB_texture_filter_minmax GL_EXT_texture_sRGB_R8 GL_EXT_texture_sRGB_RG8 GL_KHR_no_error GL_OVR_multiview2 GL_OVR_multiview_multisampled_render_to_texture GL_ARB_gl_spirv GL_EXT_clip_cull_distance GL_EXT_memory_object GL_EXT_memory_object_win32 GL_EXT_semaphore GL_EXT_semaphore_win32 GL_AMD_gpu_shader_int16 GL_ARB_polygon_offset_clamp GL_ARB_texture_filter_anisotropic GL_EXT_texture_compression_bptc GL_KHR_parallel_shader_compile GL_EXT_nonuniform_qualifier

[Sameer K]

Hey @lockca. Welcome to the Lightroom Community. I'll help you figure this out.

Your machine has an integrated AMD GPU with drivers (31.0.12044.3) from October 2022, which might not be enough for Lightroom's masks to work.

Give this a try on Windows; the GPU info & Logs location is %APPDATA%\Adobe\CameraRaw. A shortcut to get to this folder on Windows is:

• Press the Windows + R
• Enter %APPDATA%\Adobe\CameraRaw


• Rename the GPU & Logs folder in this directory by adding .old at the end. (GPU.old & Logs.old)
• Restart Lightroom Classic, which should capture the updated driver & hardware capabilities.

Let me know how it goes. Thanks!
Sameer K

[John R Ellis · Accepted solution]

"Your machine has an integrated AMD GPU with drivers (31.0.12044.3) from October 2022,"

...and update to the most recent driver by going directly to amd.com.

[lockca · Accepted solution]

Just seeing this now. Made the changes and so far it seems to be working.  Thank you so much

[lockca]

Just seeing this now. Made the changes and so far it seems to be working.  Thank you so much

[lockca]

It worked for a bit but not working again now.  I can only edit one picture then have to go change the files to .old.  I am looking for the right driver to update now but can't seem to find that either.  I only bought this computer in January as my old one was causing issues but it is no different with the new one.

[John R Ellis]

[This post contains formatting and embedded images that don't appear in email. View the post in your Web browser.]

"I am looking for the right driver to update now but can't seem to find that either."

In the Windows search box, type "system information" to run the System Information App. The System Manufacturer should be AMD; write down the System Model:

Go to AMD.com > Downloads & Support > Drivers.

Click on Search All Products and enter the model, selecting the matching model, and then click Submit:

[lockca]

I updated the driver by the instructions above, but still the same thing.  I can edit one, maybe two photos and I get the error something went wrong.  Is there anything else it could be or would you have any other suggestions that may fix.  Also, thank you so much for all the help so far with this issue

[John R Ellis]

"Dedicated GPU memory used by Lightroom: 3737.2MB / 495.5MB (754%)
DirectX: AMD Radeon(TM) Graphics (31.0.12044.3)"

LR's AI commands requires a minimum of 2 GB of graphics memory (VRAM).  It's not clear whether the integrated graphics on your AMD processor qualify -- the graphics processor (GPU) has access to 4 GB, of which most is system memory shared with the CPU and only 512 MB is dedicated to the GPU.

You could verify it's the graphics processor or its driver by booting Windows into safe mode,

which will disable the GPU while in safe mode.  LR's AI masking runs just fine (though more slowly) without a GPU.  So if the problem doesn't occur, you know for sure it's the GPU. If you're on a desktop, you could consider adding a graphics card.  But if you're on a laptop, it's probably not economically worthwhile getting an external GPU (eGPU).

LR, and your laptop overall, will probably run much too slowly in safe mode to make it practical to do that all the time.

[lockca]

Just getting around to running my computer in safe mode and Lightroom masking works. So it is the GPU.   Very disappointing seen I just purchased an all in one computer in January.  Not sure what I can do now for upgrading it or how much an external one would be.
