I can't upload SVGs to a Firefly Board. It says it's an unsupported format, BUT the SVG was generated in Adobe Illustrator.

Title: Firefly Boards rejects valid, Illustrator-exported SVG files despite listing SVG as a supported upload format

Product / Area: Adobe Firefly — Firefly Boards — asset upload

Environment

• Browser: Chrome 148.0.7778.216 (Official Build) (arm64)
• OS: macOS Sequoia 15.7.4 (24G517)
• Date/time of occurrence: July 7, 2026, ~30 minutes before filing

Summary

Firefly Boards' upload interface explicitly lists SVG as a supported file format, but it rejects valid SVG files on upload. The files were authored in Adobe Illustrator, exported through Illustrator's native SVG export, and are standards-compliant (valid XML, presentation-attribute styling, text converted to outlines, no CSS/gradients/filters/masks). The files still fail to upload.

Supported-formats claim (from the Firefly Boards UI):

The interface states that Firefly Boards supports: GIF, GLB, JPEG, JPG, MOV, MP4, PNG, QUICKTIME, SVG, WEBP. SVG is listed.

Expected behavior

A valid SVG should upload and render on the board, since SVG is a listed supported format.

Actual behavior

The upload fails and the interface surfaces its supported-formats notice (the same one that lists SVG). In other words, a file in a format the UI says is supported is being treated as unsupported or invalid.

Steps to reproduce

1. In Adobe Illustrator, create a simple two-color vector: a solid filled rectangle plus text.
2. Select the text and convert it to outlines (Type > Create Outlines), so the file contains only vector paths, no live text.
3. Go to File > Export > Export for Screens.
4. Open the format settings (gear icon), select SVG, and set:
   • Styling: Presentation Attributes
   • Font: Convert to Outlines
   • Images: Embed
   • Object IDs: Unique
   • Decimal: 2
   • Responsive: checked
   • Minify: unchecked
5. Export the SVG.
6. In Firefly Boards, attempt to upload the exported SVG onto a board.
7. Result: the upload is rejected.

Troubleshooting I already performed

Phase 1 — Illustrator export-setting variations (re-exported and re-uploaded a fresh file each time):

• Toggled Styling across Presentation Attributes, Internal CSS, and Inline Style.
• Toggled Responsive on and off (which adds/removes explicit width and height on the root <svg>).
• Varied Object IDs (Unique vs. other options).
• Scaled the artboard up (from roughly 60 × 66 to roughly 554 × 619) to rule out a minimum-dimension threshold.

Every variation was rejected on upload.

Phase 2 — Manual source editing in Visual Studio Code:

• Opened the exported SVG and edited the raw source directly, including removing the XML prolog (<?xml version="1.0" encoding="UTF-8"?>) and the Illustrator-generated identifier attributes on the root element (id="uuid-…" and data-name).
• Re-uploaded.

Still rejected.

Isolation / observation

The failure survives both native Illustrator export configurations and manual source cleanup. The sample below is a valid SVG: a single <rect> plus a <g> of <path> elements, presentation-attribute fills only, no <text>, <style>, <defs>, gradients, filters, masks, or clipping paths, and the standard SVG namespace. Because even this file is rejected, the problem appears to sit in the Firefly Boards upload validator/parser rather than in any exotic SVG feature. I'll leave root-cause to your engineers rather than guess at the internals.

Sample SVG (source pasted inline, since the form does not accept .svg attachments)

This is the scaled-up variant (viewBox 553.61 × 619.43), as exported from Illustrator with the settings above. It still carries the Illustrator-generated id="uuid-…" and data-name attributes (i.e., before the Phase 2 manual edits):

<?xml version="1.0" encoding="UTF-8"?>
<svg id="uuid-7e2f61a1-2976-40b0-8dbb-f4fce26ac6bb" data-name="Layer 1" xmlns="http://www.w3.org/2000/svg" width="553.61" height="619.43" viewBox="0 0 553.61 619.43">
  <rect x="0" width="556.61" height="620.37" fill="#e04478"/>
  <g>
    <path d="M77.65,403.1h13.92c1.46,0,2.83.15,4.1.44,1.28.3,2.4.78,3.37,1.45s1.72,1.55,2.27,2.64c.54,1.09.81,2.44.81,4.07,0,2.23-.63,4.13-1.89,5.67s-3.01,2.5-5.25,2.87v.09c1.52.18,2.73.59,3.61,1.21.89.62,1.55,1.39,1.99,2.29s.71,1.9.84,2.99c.13,1.09.18,2.17.18,3.26v1.92c0,.62.04,1.2.1,1.75s.16,1.05.3,1.51c.15.47.34.86.58,1.17h-2.28c-.44-.78-.68-1.69-.73-2.73-.05-1.05-.07-2.12-.07-3.25s-.05-2.23-.14-3.34c-.1-1.1-.39-2.1-.88-2.96-.5-.88-1.29-1.58-2.36-2.11-1.07-.53-2.59-.79-4.55-.79h-11.86v15.17h-2.06v-33.33ZM91.56,419.49c1.21,0,2.33-.15,3.38-.45,1.05-.29,1.94-.76,2.69-1.38s1.33-1.41,1.77-2.38.66-2.12.66-3.46c0-1.24-.24-2.31-.7-3.2-.47-.88-1.09-1.61-1.87-2.17-.78-.56-1.68-.97-2.71-1.21s-2.11-.37-3.22-.37h-11.86v14.62h11.86Z" fill="#fff"/>
    <path d="M105.84,419.95c0-2.36.36-4.61,1.06-6.75.69-2.13,1.71-4,3.05-5.63,1.34-1.61,2.98-2.9,4.92-3.85s4.19-1.42,6.7-1.42c1.71,0,3.35.25,4.91.74,1.55.5,2.95,1.23,4.18,2.2,1.22.97,2.26,2.13,3.1,3.5s1.4,2.93,1.68,4.67h-1.95c-.78-2.93-2.19-5.22-4.21-6.87-2.02-1.64-4.57-2.47-7.65-2.47-2.24,0-4.22.44-5.93,1.3-1.71.88-3.15,2.04-4.3,3.5-1.15,1.47-2.02,3.16-2.62,5.07s-.88,3.91-.88,6,.28,4.11.86,6c.58,1.88,1.44,3.52,2.57,4.92s2.56,2.52,4.27,3.34c1.71.83,3.72,1.24,6.03,1.24,2,0,3.78-.33,5.37-.98,1.59-.65,2.94-1.57,4.03-2.75,1.11-1.19,1.94-2.61,2.5-4.27.57-1.67.8-3.53.71-5.58h-12.28v-1.78h14.05v16.34h-1.77v-7.09h-.1c-.4,1.21-1.01,2.31-1.81,3.29-.82.98-1.77,1.81-2.88,2.47-1.09.67-2.33,1.19-3.68,1.57s-2.76.56-4.22.56c-2.53,0-4.75-.45-6.7-1.35-1.95-.9-3.59-2.13-4.92-3.69-1.34-1.55-2.35-3.38-3.04-5.48-.68-2.11-1.03-4.35-1.03-6.75Z" fill="#fff"/>
    <path d="M141.66,403.1h13.35c1.99,0,3.66.25,5,.74,1.33.5,2.41,1.16,3.22,1.97.81.8,1.4,1.73,1.75,2.77.36,1.05.54,2.1.54,3.16,0,.9-.16,1.76-.47,2.56-.31.81-.75,1.53-1.32,2.15s-1.27,1.14-2.05,1.56c-.8.42-1.68.69-2.64.82l.09.09c.22-.03.73.06,1.55.28.8.22,1.65.63,2.54,1.24.89.6,1.69,1.44,2.39,2.52.69,1.08,1.05,2.45,1.05,4.13,0,1.53-.28,2.86-.85,4.02-.56,1.15-1.34,2.12-2.35,2.92s-2.23,1.39-3.67,1.8c-1.43.4-3.02.6-4.76.6h-13.35v-33.33ZM155.01,418.22c2.83,0,4.94-.63,6.35-1.89s2.1-2.92,2.1-4.97c0-1.21-.23-2.23-.69-3.06-.47-.82-1.09-1.49-1.87-2.01-.78-.51-1.67-.88-2.69-1.09-1-.22-2.07-.33-3.19-.33h-11.3v13.35h11.3ZM155.01,434.66c2.99,0,5.33-.63,7.02-1.9,1.7-1.26,2.55-3.15,2.55-5.67,0-1.43-.3-2.61-.89-3.52-.58-.92-1.35-1.64-2.26-2.17-.92-.53-1.95-.89-3.08-1.1-1.13-.2-2.24-.3-3.34-.3h-11.3v14.66h11.3Z" fill="#fff"/>
    <path d="M173.41,412.44h2.38v4.81h-2.38v-4.81ZM173.41,431.63h2.38v4.81h-2.38v-4.81Z" fill="#fff"/>
    <path d="M197.26,432.39c.59-1.19,1.35-2.29,2.27-3.26.91-.98,1.94-1.89,3.08-2.74,1.13-.84,2.29-1.64,3.47-2.43,1.15-.78,2.29-1.56,3.4-2.35,1.13-.79,2.13-1.64,3.02-2.54s1.6-1.9,2.12-2.97c.53-1.07.79-2.29.79-3.66,0-1.09-.22-2.08-.66-2.97-.43-.88-1.01-1.64-1.75-2.28-.73-.64-1.57-1.13-2.53-1.48-.95-.34-1.95-.51-3.01-.51-1.46,0-2.74.26-3.83.77-1.09.52-1.99,1.22-2.7,2.11-.72.88-1.26,1.93-1.61,3.13s-.54,2.5-.54,3.89h-1.77c.18-3.92,1.12-6.8,2.83-8.65,1.7-1.85,4.14-2.78,7.35-2.78,1.37,0,2.66.18,3.87.54,1.22.36,2.28.9,3.18,1.63s1.61,1.65,2.14,2.75.8,2.41.8,3.9c0,1.9-.45,3.57-1.33,5.02-.89,1.45-2.01,2.76-3.37,3.95-1.36,1.18-2.82,2.29-4.39,3.31-1.58,1.03-3.05,2.05-4.44,3.06s-2.56,2.07-3.55,3.17-1.53,2.33-1.66,3.67h19.24v1.77h-21.49c.1-1.5.44-2.84,1.03-4.04Z" fill="#fff"/>
    <path d="M223.23,432.39c.59-1.19,1.35-2.29,2.26-3.26.92-.98,1.95-1.89,3.08-2.74,1.14-.84,2.3-1.64,3.48-2.43,1.15-.78,2.28-1.56,3.41-2.35,1.11-.79,2.12-1.64,3.01-2.54.88-.9,1.59-1.9,2.12-2.97.53-1.07.79-2.29.79-3.66,0-1.09-.22-2.08-.66-2.97-.44-.88-1.02-1.64-1.75-2.28s-1.57-1.13-2.52-1.48c-.95-.34-1.95-.51-3.01-.51-1.47,0-2.74.26-3.83.77-1.09.52-2,1.22-2.72,2.11-.71.88-1.25,1.93-1.61,3.13-.36,1.19-.54,2.5-.54,3.89h-1.78c.19-3.92,1.13-6.8,2.83-8.65s4.15-2.78,7.35-2.78c1.38,0,2.66.18,3.88.54,1.21.36,2.27.9,3.17,1.63s1.62,1.65,2.15,2.75.78,2.41.78,3.9c0,1.9-.44,3.57-1.33,5.02-.88,1.45-2.01,2.76-3.36,3.95-1.35,1.18-2.82,2.29-4.4,3.31-1.57,1.03-3.05,2.05-4.43,3.06s-2.57,2.07-3.55,3.17-1.53,2.33-1.65,3.67h19.22v1.77h-21.47c.09-1.5.44-2.84,1.02-4.04Z" fill="#fff"/>
    <path d="M247.37,426.45l15.69-22.23h1.77v22.46h5.42v1.54h-5.42v8.22h-1.77v-8.22h-15.69v-1.77ZM263.06,426.67v-20.03h-.1l-13.82,20.03h13.92Z" fill="#fff"/>
    <path d="M277.25,431.63h2.38v4.81h-2.38v-4.81Z" fill="#fff"/>
    <path d="M298.4,437c-2.23,0-4.09-.42-5.58-1.27-1.48-.84-2.65-1.95-3.53-3.34-.87-1.38-1.48-2.98-1.84-4.81-.36-1.82-.53-3.71-.53-5.67,0-1.3.05-2.67.18-4.09s.35-2.8.67-4.16c.33-1.35.77-2.64,1.33-3.85s1.29-2.28,2.17-3.2c.89-.92,1.95-1.64,3.17-2.17,1.23-.53,2.67-.79,4.32-.79,2.74,0,4.99.73,6.75,2.2,1.75,1.46,2.79,3.57,3.1,6.3h-1.77c-.18-1.03-.51-1.97-.98-2.83-.47-.86-1.05-1.59-1.75-2.2-.69-.6-1.5-1.08-2.41-1.42-.89-.34-1.88-.51-2.94-.51-2.21,0-3.99.57-5.33,1.72-1.33,1.16-2.35,2.58-3.05,4.28s-1.16,3.52-1.38,5.46-.33,3.71-.33,5.3l.09.09c.35-1.02.84-1.97,1.5-2.82.66-.86,1.4-1.6,2.24-2.2.84-.61,1.75-1.08,2.75-1.4.99-.33,2.04-.48,3.13-.48,1.59,0,3.04.27,4.37.84,1.32.56,2.46,1.33,3.41,2.31.95.98,1.68,2.14,2.21,3.48.53,1.33.8,2.8.8,4.39s-.27,2.99-.82,4.31c-.55,1.33-1.29,2.47-2.24,3.44s-2.08,1.71-3.41,2.26c-1.31.55-2.75.82-4.31.82ZM289.29,426.16c0,1.34.25,2.57.73,3.71s1.13,2.12,1.93,2.94c.81.83,1.77,1.48,2.88,1.94,1.09.47,2.29.7,3.57.7s2.51-.26,3.6-.75c1.08-.5,2.03-1.17,2.85-2.01.8-.85,1.44-1.82,1.89-2.95s.67-2.32.67-3.59-.23-2.44-.67-3.59c-.45-1.16-1.08-2.17-1.87-3.04-.79-.88-1.74-1.57-2.85-2.08-1.11-.51-2.32-.78-3.62-.78s-2.56.26-3.67.75c-1.1.5-2.06,1.18-2.87,2.03-.8.86-1.44,1.86-1.89,3.01-.45,1.16-.68,2.38-.68,3.69Z" fill="#fff"/>
    <path d="M312.73,427.19c0-2.33.63-4.24,1.89-5.72,1.27-1.48,3.02-2.34,5.25-2.59v-.09c-1.95-.37-3.43-1.19-4.43-2.45-.99-1.26-1.5-2.79-1.5-4.6,0-1.52.28-2.8.84-3.83.57-1.03,1.31-1.85,2.24-2.47.93-.63,1.99-1.08,3.17-1.36s2.42-.42,3.69-.42,2.47.14,3.67.42,2.26.73,3.2,1.36c.93.62,1.68,1.44,2.24,2.47.55,1.03.84,2.31.84,3.83,0,1.81-.5,3.34-1.5,4.6-1,1.26-2.48,2.08-4.44,2.45v.09c2.24.25,3.99,1.11,5.25,2.59,1.27,1.48,1.89,3.38,1.89,5.72,0,1.69-.29,3.14-.88,4.37-.6,1.23-1.39,2.25-2.39,3.06-.99.8-2.18,1.4-3.55,1.8-1.37.38-2.82.58-4.34.58s-3.02-.2-4.37-.58c-1.35-.39-2.53-.99-3.52-1.8-1-.81-1.79-1.83-2.39-3.06-.58-1.23-.88-2.68-.88-4.37ZM314.51,427.19c0,1.44.26,2.67.77,3.72.51,1.04,1.2,1.9,2.06,2.56.86.67,1.84,1.17,2.98,1.5s2.33.49,3.57.49,2.43-.16,3.55-.49,2.12-.82,2.99-1.5c.87-.67,1.56-1.52,2.08-2.56.51-1.05.77-2.28.77-3.72,0-1.33-.26-2.48-.75-3.43s-1.19-1.72-2.05-2.33c-.88-.6-1.88-1.05-3.02-1.33-1.13-.27-2.32-.42-3.57-.42s-2.47.15-3.6.42c-1.11.28-2.12.73-2.98,1.33-.87.61-1.56,1.39-2.05,2.33-.5.95-.75,2.1-.75,3.43ZM323.89,418.13c1.03,0,2.03-.12,3.01-.35.98-.24,1.85-.61,2.62-1.12s1.38-1.18,1.84-1.99c.47-.8.7-1.79.7-2.94,0-1.21-.23-2.24-.68-3.08-.45-.84-1.06-1.52-1.81-2.03s-1.63-.88-2.62-1.09-2-.33-3.05-.33-2.08.11-3.05.33c-.98.22-1.86.58-2.62,1.09-.77.51-1.38,1.19-1.82,2.03s-.67,1.87-.67,3.08c0,1.15.23,2.13.7,2.94.47.81,1.08,1.48,1.84,1.99s1.63.88,2.61,1.12c.98.23,1.99.35,3.02.35Z" fill="#fff"/>
    <path d="M342.14,431.63h2.39v4.81h-2.39v-4.81Z" fill="#fff"/>
    <path d="M363.54,407.67c-1.15,1.21-2.48,2.17-3.98,2.85s-3.05,1.1-4.67,1.26v-1.54c1.88-.28,3.57-.93,5.09-1.96,1.53-1.03,2.77-2.38,3.74-4.07h1.59v32.22h-1.77v-28.76Z" fill="#fff"/>
    <path d="M378.98,432.39c.59-1.19,1.35-2.29,2.26-3.26.92-.98,1.95-1.89,3.08-2.74,1.14-.84,2.3-1.64,3.48-2.43,1.15-.78,2.28-1.56,3.41-2.35,1.11-.79,2.12-1.64,3.01-2.54.88-.9,1.59-1.9,2.12-2.97.53-1.07.79-2.29.79-3.66,0-1.09-.22-2.08-.66-2.97-.44-.88-1.02-1.64-1.75-2.28s-1.57-1.13-2.52-1.48c-.95-.34-1.95-.51-3.01-.51-1.47,0-2.74.26-3.83.77-1.09.52-2,1.22-2.72,2.11-.71.88-1.25,1.93-1.61,3.13-.36,1.19-.54,2.5-.54,3.89h-1.78c.19-3.92,1.13-6.8,2.83-8.65s4.15-2.78,7.35-2.78c1.38,0,2.66.18,3.88.54,1.21.36,2.27.9,3.17,1.63s1.62,1.65,2.15,2.75.78,2.41.78,3.9c0,1.9-.44,3.57-1.33,5.02-.88,1.45-2.01,2.76-3.36,3.95-1.35,1.18-2.82,2.29-4.4,3.31-1.57,1.03-3.05,2.05-4.43,3.06s-2.57,2.07-3.55,3.17-1.53,2.33-1.65,3.67h19.22v1.77h-21.47c.09-1.5.44-2.84,1.02-4.04Z" fill="#fff"/>
    <path d="M414.75,437c-2.33,0-4.25-.51-5.75-1.52-1.49-1.01-2.68-2.32-3.57-3.92s-1.5-3.39-1.85-5.37c-.34-1.97-.51-3.92-.51-5.85s.17-3.88.51-5.86c.35-1.97.97-3.77,1.85-5.37.88-1.6,2.08-2.91,3.57-3.92,1.5-1,3.41-1.51,5.75-1.51s4.25.51,5.75,1.51c1.5,1.01,2.68,2.33,3.57,3.92.88,1.61,1.5,3.4,1.84,5.37.35,1.98.51,3.93.51,5.86s-.16,3.88-.51,5.85c-.35,1.98-.96,3.77-1.84,5.37-.89,1.61-2.08,2.91-3.57,3.92s-3.41,1.52-5.75,1.52ZM414.75,435.46c2,0,3.64-.48,4.92-1.45,1.29-.97,2.31-2.2,3.05-3.68.73-1.5,1.23-3.14,1.51-4.91.27-1.78.42-3.47.42-5.09s-.15-3.32-.42-5.09c-.28-1.78-.78-3.41-1.51-4.91-.74-1.5-1.75-2.72-3.05-3.68-1.29-.97-2.93-1.45-4.92-1.45s-3.67.48-4.94,1.45-2.28,2.19-3.01,3.68c-.74,1.5-1.24,3.13-1.52,4.91-.28,1.77-.42,3.47-.42,5.09s.14,3.31.42,5.09c.28,1.77.78,3.41,1.52,4.91.73,1.49,1.73,2.72,3.01,3.68s2.92,1.45,4.94,1.45Z" fill="#fff"/>
    <path d="M77.65,459.13h2.06v15.12h21.28v-15.12h2.06v33.33h-2.06v-16.43h-21.28v16.43h-2.06v-33.33Z" fill="#fff"/>
    <path d="M108.92,459.13h22.42v1.77h-20.35v13.35h19.14v1.78h-19.14v14.66h20.59v1.77h-22.65v-33.33Z" fill="#fff"/>
    <path d="M132.18,459.13h2.38l10.55,14.65,10.79-14.65h2.33l-11.76,16.2,12.42,17.14h-2.47l-11.31-15.59-11.34,15.59h-2.43l12.51-17.14-11.67-16.2Z" fill="#fff"/>
    <path d="M163.37,468.47h2.39v4.81h-2.39v-4.81ZM163.37,487.66h2.39v4.81h-2.39v-4.81Z" fill="#fff"/>
    <path d="M187.32,480.7v.28c0,1.4.19,2.74.56,4.01.38,1.28.93,2.4,1.66,3.37.74.97,1.66,1.72,2.77,2.29,1.1.56,2.39.84,3.86.84,2.4,0,4.31-.63,5.72-1.9,1.4-1.26,2.37-3.01,2.9-5.25h1.77c-.53,2.81-1.67,4.95-3.43,6.45s-4.09,2.24-6.99,2.24c-1.77,0-3.32-.32-4.64-.96s-2.43-1.51-3.31-2.62c-.89-1.1-1.55-2.41-1.99-3.92s-.66-3.14-.66-4.88.23-3.29.67-4.83c.46-1.54,1.13-2.89,2.04-4.06.89-1.17,2.02-2.11,3.37-2.81,1.36-.69,2.95-1.05,4.8-1.05,1.68,0,3.16.31,4.45.94,1.29.62,2.37,1.47,3.25,2.54.88,1.07,1.53,2.32,1.99,3.73.45,1.42.67,2.94.67,4.55,0,.16,0,.34-.02.54-.02.2-.03.36-.03.49h-19.42ZM204.97,479.16c-.05-1.3-.27-2.54-.66-3.71-.36-1.17-.93-2.2-1.66-3.08s-1.62-1.6-2.66-2.12c-1.05-.53-2.24-.79-3.58-.79-1.43,0-2.71.27-3.79.82-1.09.54-2.02,1.26-2.76,2.14s-1.33,1.92-1.73,3.11c-.4,1.18-.66,2.4-.75,3.64h17.6Z" fill="#fff"/>
    <path d="M221.27,493.03c-2.33,0-4.25-.51-5.75-1.52s-2.69-2.32-3.57-3.92c-.89-1.61-1.5-3.39-1.84-5.37-.35-1.97-.51-3.92-.51-5.85s.16-3.88.51-5.86c.34-1.97.95-3.77,1.84-5.37.88-1.6,2.08-2.91,3.57-3.92,1.5-1,3.41-1.51,5.75-1.51s4.25.51,5.74,1.51c1.5,1.01,2.69,2.33,3.57,3.92.88,1.61,1.5,3.4,1.84,5.37.34,1.98.52,3.93.52,5.86s-.18,3.88-.52,5.85c-.34,1.98-.96,3.77-1.84,5.37s-2.08,2.91-3.57,3.92c-1.49,1.01-3.4,1.52-5.74,1.52ZM221.27,491.49c1.99,0,3.63-.48,4.92-1.45,1.29-.97,2.3-2.2,3.03-3.68.73-1.5,1.24-3.14,1.51-4.91.29-1.78.43-3.47.43-5.09s-.14-3.32-.43-5.09c-.27-1.78-.78-3.41-1.51-4.91s-1.74-2.72-3.03-3.68c-1.29-.97-2.94-1.45-4.92-1.45s-3.68.48-4.96,1.45-2.28,2.19-3.01,3.68-1.24,3.13-1.51,4.91c-.27,1.77-.42,3.47-.42,5.09s.15,3.31.42,5.09c.27,1.77.78,3.41,1.51,4.91.73,1.49,1.73,2.72,3.01,3.68s2.94,1.45,4.96,1.45Z" fill="#fff"/>
    <path d="M235.6,482.48l15.69-22.23h1.77v22.46h5.42v1.54h-5.42v8.22h-1.77v-8.22h-15.69v-1.77ZM251.3,482.7v-20.03h-.1l-13.82,20.03h13.92Z" fill="#fff"/>
    <path d="M261.56,482.48l15.69-22.23h1.77v22.46h5.42v1.54h-5.42v8.22h-1.77v-8.22h-15.69v-1.77ZM277.25,482.7v-20.03h-.09l-13.82,20.03h13.92Z" fill="#fff"/>
    <path d="M294.59,485.46c.46-2.36,1.19-4.8,2.23-7.3,1.02-2.51,2.41-5.12,4.18-7.82,1.75-2.71,4.01-5.55,6.78-8.54h-19v-1.54h20.78v1.78c-1.61,1.81-3.18,3.66-4.7,5.55-1.5,1.91-2.87,4.03-4.1,6.4-1.23,2.36-2.29,5.05-3.17,8.05-.89,3-1.51,6.48-1.9,10.43h-2.05c.19-2.3.5-4.63.96-7Z" fill="#fff"/>
    <path d="M313.95,483.21c0-2.33.64-4.24,1.9-5.72s3.01-2.34,5.25-2.59v-.09c-1.97-.37-3.45-1.19-4.44-2.45s-1.49-2.79-1.49-4.6c0-1.52.27-2.8.84-3.83.56-1.03,1.3-1.85,2.23-2.47.94-.63,2-1.08,3.18-1.36,1.18-.28,2.41-.42,3.68-.42s2.46.14,3.67.42c1.19.28,2.26.73,3.19,1.36.94.62,1.69,1.44,2.24,2.47.57,1.03.84,2.31.84,3.83,0,1.81-.49,3.34-1.5,4.6-.98,1.26-2.47,2.08-4.43,2.45v.09c2.24.25,3.99,1.11,5.25,2.59s1.9,3.38,1.9,5.72c0,1.69-.3,3.14-.89,4.37-.58,1.23-1.39,2.25-2.38,3.06-.99.8-2.18,1.4-3.55,1.8-1.37.38-2.82.58-4.34.58s-3.01-.2-4.37-.58c-1.36-.39-2.53-.99-3.53-1.8-.98-.81-1.79-1.83-2.37-3.06-.6-1.23-.89-2.68-.89-4.37ZM315.71,483.21c0,1.44.26,2.67.78,3.72.52,1.04,1.19,1.9,2.05,2.56.86.67,1.86,1.17,2.99,1.5s2.33.49,3.57.49,2.43-.16,3.55-.49,2.12-.82,2.98-1.5c.88-.67,1.57-1.52,2.08-2.56.52-1.05.78-2.28.78-3.72,0-1.33-.25-2.48-.75-3.43s-1.18-1.72-2.05-2.33c-.88-.6-1.88-1.05-3.01-1.33-1.14-.27-2.33-.42-3.57-.42s-2.48.15-3.59.42c-1.13.28-2.12.73-2.99,1.33-.88.61-1.56,1.39-2.06,2.33-.49.95-.75,2.1-.75,3.43ZM325.11,474.16c1.02,0,2.02-.12,3.01-.35.98-.24,1.85-.61,2.62-1.12.76-.51,1.38-1.18,1.84-1.99.47-.8.7-1.79.7-2.94,0-1.21-.23-2.24-.67-3.08-.46-.84-1.06-1.52-1.82-2.03s-1.64-.88-2.62-1.09-2-.33-3.05-.33-2.08.11-3.06.33c-.98.22-1.84.58-2.61,1.09s-1.37,1.19-1.82,2.03-.67,1.87-.67,3.08c0,1.15.24,2.13.69,2.94.47.81,1.09,1.48,1.85,1.99.76.51,1.63.88,2.62,1.12.98.23,1.98.35,3.01.35Z" fill="#fff"/>
    <path d="M76.39,531.82c0-2.43.36-4.71,1.08-6.84.71-2.12,1.75-3.99,3.1-5.55s3.02-2.81,5-3.71c1.97-.9,4.21-1.35,6.69-1.35,1.97,0,3.67.26,5.09.77,1.44.51,2.64,1.15,3.63,1.92.98.77,1.78,1.6,2.4,2.5.63.9,1.1,1.75,1.43,2.54.32.79.55,1.48.67,2.05.12.57.18.89.18.96h-2.05c-.22-1.4-.67-2.65-1.36-3.76-.68-1.1-1.53-2.04-2.57-2.83-1.02-.78-2.17-1.37-3.43-1.77-1.26-.41-2.59-.61-3.99-.61-2.17,0-4.12.42-5.84,1.26-1.71.84-3.16,1.97-4.34,3.39-1.19,1.41-2.08,3.07-2.7,4.97-.63,1.9-.94,3.92-.94,6.06s.31,4.18.94,6.07c.62,1.9,1.51,3.56,2.7,4.97,1.19,1.42,2.64,2.54,4.34,3.38,1.71.85,3.67,1.27,5.84,1.27,1.62,0,3.14-.34,4.56-1,1.41-.67,2.65-1.56,3.71-2.66s1.91-2.38,2.54-3.83,1-2.95,1.09-4.5h2.06c-.19,1.99-.67,3.83-1.48,5.51-.79,1.68-1.81,3.14-3.03,4.37-1.24,1.23-2.66,2.19-4.28,2.87s-3.35,1.02-5.19,1.02c-2.48,0-4.72-.45-6.69-1.35-1.98-.9-3.65-2.14-5-3.71-1.35-1.58-2.39-3.43-3.1-5.56-.72-2.12-1.08-4.4-1.08-6.84Z" fill="#fff"/>
    <path d="M110.51,515.16h2.95l13.03,31.04h.09l12.89-31.04h2.95v33.33h-2.06v-30.81h-.09l-12.69,30.81h-2.06l-12.84-30.81h-.09v30.81h-2.06v-33.33Z" fill="#fff"/>
    <path d="M170.84,515.16h2.28l-13.4,19.37v13.96h-2.05v-13.96l-13.31-19.37h2.33l12.06,17.65,12.09-17.65Z" fill="#fff"/>
    <path d="M175.09,515.16h2.05v19.19l20.97-19.19h2.66l-15.23,13.86,16.16,19.47h-2.57l-15.08-18.07-6.9,6.3v11.76h-2.05v-33.33Z" fill="#fff"/>
    <path d="M206.05,524.5h2.38v4.81h-2.38v-4.81ZM206.05,543.68h2.38v4.81h-2.38v-4.81Z" fill="#fff"/>
    <path d="M235.15,541.49c.46-2.36,1.19-4.8,2.23-7.3,1.02-2.51,2.41-5.12,4.18-7.82,1.75-2.71,4.01-5.55,6.78-8.54h-19v-1.54h20.78v1.78c-1.61,1.81-3.18,3.66-4.7,5.55-1.5,1.91-2.87,4.03-4.1,6.4-1.23,2.36-2.29,5.05-3.17,8.05-.89,3-1.51,6.48-1.9,10.43h-2.05c.19-2.3.5-4.63.96-7Z" fill="#fff"/>
    <path d="M257.97,543.68h2.37v4.81h-2.37v-4.81Z" fill="#fff"/>
    <path d="M267.49,539.24c0-2.33.63-4.24,1.89-5.72,1.27-1.48,3.02-2.34,5.25-2.59v-.09c-1.96-.37-3.44-1.19-4.44-2.45-.98-1.26-1.49-2.79-1.49-4.6,0-1.52.28-2.8.84-3.83s1.3-1.85,2.23-2.47c.94-.63,2-1.08,3.18-1.36,1.18-.28,2.42-.42,3.69-.42s2.46.14,3.67.42c1.19.28,2.26.73,3.19,1.36.93.62,1.68,1.44,2.24,2.47.56,1.03.84,2.31.84,3.83,0,1.81-.49,3.34-1.5,4.6-.99,1.26-2.48,2.08-4.43,2.45v.09c2.24.25,3.99,1.11,5.25,2.59s1.89,3.38,1.89,5.72c0,1.69-.3,3.14-.88,4.37-.59,1.23-1.39,2.25-2.39,3.06-.98.8-2.17,1.4-3.54,1.8-1.37.38-2.83.58-4.34.58s-3.02-.2-4.38-.58c-1.35-.39-2.52-.99-3.52-1.8-.99-.81-1.79-1.83-2.38-3.06s-.88-2.68-.88-4.37ZM269.26,539.24c0,1.44.26,2.67.77,3.72.52,1.04,1.2,1.9,2.06,2.56.86.67,1.85,1.17,2.99,1.5,1.13.33,2.33.49,3.57.49s2.43-.16,3.54-.49c1.13-.33,2.12-.82,2.99-1.5.88-.67,1.57-1.52,2.08-2.56.51-1.05.77-2.28.77-3.72,0-1.33-.25-2.48-.75-3.43-.49-.95-1.18-1.72-2.04-2.33-.88-.6-1.88-1.05-3.02-1.33-1.14-.27-2.33-.42-3.57-.42s-2.48.15-3.6.42c-1.12.28-2.12.73-2.98,1.33-.88.61-1.57,1.39-2.06,2.33s-.75,2.1-.75,3.43ZM278.65,530.19c1.02,0,2.02-.12,3.01-.35.98-.24,1.84-.61,2.61-1.12s1.39-1.18,1.84-1.99c.47-.8.71-1.79.71-2.94,0-1.21-.24-2.24-.68-3.08s-1.06-1.52-1.81-2.03c-.77-.51-1.64-.88-2.63-1.09-.98-.22-1.99-.33-3.05-.33s-2.08.11-3.06.33-1.85.58-2.61,1.09c-.77.51-1.38,1.19-1.82,2.03-.46.84-.67,1.87-.67,3.08,0,1.15.23,2.13.69,2.94.47.81,1.08,1.48,1.84,1.99s1.64.88,2.62,1.12c.98.23,1.98.35,3.02.35Z" fill="#fff"/>
    <path d="M293.45,539.24c0-2.33.64-4.24,1.9-5.72s3.01-2.34,5.25-2.59v-.09c-1.96-.37-3.44-1.19-4.43-2.45-1-1.26-1.5-2.79-1.5-4.6,0-1.52.27-2.8.84-3.83s1.31-1.85,2.24-2.47c.93-.63,1.99-1.08,3.17-1.36s2.41-.42,3.68-.42,2.47.14,3.67.42c1.2.28,2.26.73,3.2,1.36.94.62,1.69,1.44,2.24,2.47s.84,2.31.84,3.83c0,1.81-.5,3.34-1.5,4.6s-2.47,2.08-4.44,2.45v.09c2.24.25,3.99,1.11,5.25,2.59,1.27,1.48,1.9,3.38,1.9,5.72,0,1.69-.29,3.14-.88,4.37s-1.39,2.25-2.38,3.06c-1,.8-2.19,1.4-3.56,1.8-1.37.38-2.81.58-4.34.58s-3.01-.2-4.36-.58c-1.36-.39-2.54-.99-3.53-1.8-.99-.81-1.79-1.83-2.38-3.06s-.89-2.68-.89-4.37ZM295.22,539.24c0,1.44.26,2.67.78,3.72.51,1.04,1.19,1.9,2.05,2.56.86.67,1.85,1.17,2.98,1.5,1.14.33,2.33.49,3.57.49s2.43-.16,3.56-.49c1.11-.33,2.12-.82,2.98-1.5.87-.67,1.56-1.52,2.08-2.56.52-1.05.78-2.28.78-3.72,0-1.33-.26-2.48-.75-3.43-.5-.95-1.19-1.72-2.06-2.33-.88-.6-1.88-1.05-3.01-1.33-1.13-.27-2.33-.42-3.57-.42s-2.47.15-3.59.42c-1.12.28-2.12.73-2.99,1.33-.87.61-1.55,1.39-2.05,2.33s-.75,2.1-.75,3.43ZM304.61,530.19c1.03,0,2.03-.12,3.01-.35.98-.24,1.86-.61,2.63-1.12.76-.51,1.37-1.18,1.84-1.99.47-.8.69-1.79.69-2.94,0-1.21-.22-2.24-.67-3.08s-1.06-1.52-1.82-2.03c-.76-.51-1.63-.88-2.61-1.09-.98-.22-2.01-.33-3.06-.33s-2.08.11-3.05.33-1.85.58-2.62,1.09-1.37,1.19-1.82,2.03c-.45.84-.67,1.87-.67,3.08,0,1.15.24,2.13.7,2.94.47.81,1.09,1.48,1.85,1.99.76.51,1.62.88,2.61,1.12.98.23,1.99.35,3.01.35Z" fill="#fff"/>
    <path d="M322.86,543.68h2.38v4.81h-2.38v-4.81Z" fill="#fff"/>
    <path d="M331.93,538.51l15.69-22.23h1.77v22.46h5.42v1.54h-5.42v8.22h-1.77v-8.22h-15.69v-1.77ZM347.61,538.73v-20.03h-.09l-13.82,20.03h13.92Z" fill="#fff"/>
    <path d="M369.51,549.06c-2.33,0-4.25-.51-5.75-1.52-1.49-1.01-2.69-2.32-3.57-3.92-.89-1.61-1.51-3.39-1.85-5.37-.34-1.97-.51-3.92-.51-5.85s.17-3.88.51-5.86c.34-1.97.96-3.77,1.85-5.37.88-1.6,2.08-2.91,3.57-3.92,1.5-1,3.41-1.51,5.75-1.51s4.25.51,5.74,1.51c1.5,1.01,2.69,2.33,3.57,3.92.89,1.61,1.5,3.4,1.84,5.37.35,1.98.52,3.93.52,5.86s-.17,3.88-.52,5.85c-.34,1.98-.95,3.77-1.84,5.37-.88,1.61-2.08,2.91-3.57,3.92-1.49,1.01-3.4,1.52-5.74,1.52ZM369.51,547.52c2,0,3.64-.48,4.92-1.45s2.31-2.2,3.04-3.68c.73-1.5,1.24-3.14,1.51-4.91.28-1.78.42-3.47.42-5.09s-.14-3.32-.42-5.09c-.27-1.78-.78-3.41-1.51-4.91s-1.75-2.72-3.04-3.68-2.93-1.45-4.92-1.45-3.68.48-4.95,1.45-2.28,2.19-3.01,3.68-1.24,3.13-1.51,4.91c-.28,1.77-.42,3.47-.42,5.09s.14,3.31.42,5.09c.27,1.77.78,3.41,1.51,4.91.73,1.49,1.73,2.72,3.01,3.68s2.93,1.45,4.95,1.45Z" fill="#fff"/>
    <path d="M387.77,543.68h2.38v4.81h-2.38v-4.81Z" fill="#fff"/>
    <path d="M408.45,549.06c-2.33,0-4.25-.51-5.75-1.52-1.49-1.01-2.69-2.32-3.57-3.92-.89-1.61-1.51-3.39-1.85-5.37-.34-1.97-.51-3.92-.51-5.85s.17-3.88.51-5.86c.34-1.97.96-3.77,1.85-5.37.88-1.6,2.08-2.91,3.57-3.92,1.5-1,3.41-1.51,5.75-1.51s4.25.51,5.74,1.51c1.5,1.01,2.69,2.33,3.57,3.92.89,1.61,1.5,3.4,1.84,5.37.35,1.98.52,3.93.52,5.86s-.17,3.88-.52,5.85c-.34,1.98-.95,3.77-1.84,5.37-.88,1.61-2.08,2.91-3.57,3.92-1.49,1.01-3.4,1.52-5.74,1.52ZM408.45,547.52c2,0,3.64-.48,4.92-1.45s2.31-2.2,3.04-3.68c.73-1.5,1.24-3.14,1.51-4.91.28-1.78.42-3.47.42-5.09s-.14-3.32-.42-5.09c-.27-1.78-.78-3.41-1.51-4.91s-1.75-2.72-3.04-3.68-2.93-1.45-4.92-1.45-3.68.48-4.95,1.45-2.28,2.19-3.01,3.68-1.24,3.13-1.51,4.91c-.28,1.77-.42,3.47-.42,5.09s.14,3.31.42,5.09c.27,1.77.78,3.41,1.51,4.91.73,1.49,1.73,2.72,3.01,3.68s2.93,1.45,4.95,1.45Z" fill="#fff"/>
  </g>
</svg>
