Anchored text Box in paragraph

  • May 18, 2022
  • 3 replies
  • 865 views

I am typesetting a long journal which also has text boxes. I decided to make these text boxes in-line.

However when i go back and format the text,  these text boxes at the start of a page move to the previous page. This then overlaps the main body text.



See image below.

Originally the paragraph marks on the bottom of page 55 were not there.

The orange box on page 56 was on page 55 and the body text (which comes after the orange box below) was actually covered by the orange box.



How do i ensure that the orange box never overlaps the body text.



This topic has been closed for replies.
Correct answer Geоrge

Yep, only frame without text. But paragraph style with shading feature is better.



3 replies

Willi Adelberger
Community Expert
Willi AdelbergerCommunity Expert
Community Expert
May 18, 2022

I do not understand you layout generally:

  1. When you want to have text with a coloured background, use paragraph shading, it can have a round colored attribute.
  2. When you want to anchor objects into a text flow anchor them either in the paragraph before as the first line is ignored or create a separate paragraph (with automatic leading paragraph style). With the paragraph keep options you can define where the paragraph is positioned.
  3. You have a 2 column layout (which makes no sense since InDesign CS5) and a single column text. Make a single column text. If you want to have more columns, do it via object styles, as this gives you more flexibility.
  4. You have a bunch of succeeding returns. Avoid that. Use keep options in the paragraph styles instead.



More advices are possible, but we would need more input.

S
Summayah5FC7Author
Inspiring
May 18, 2022

thank you for the tips.



Unfortunately the document was set-up. by someone else.

S
Summayah5FC7Author
Inspiring
May 18, 2022

I've had a go with the paragraph shading.

Make one style for the header with orange shading, and offset/rounded corners at top.

Make another for the bulleted list with orange shading and offset/rounded corners at bottom.

Peter Kahrel
Community Expert
Peter KahrelCommunity Expert
Community Expert
May 18, 2022

The box moves because for InDesign purposes, inline frames are single characters.  When you add text the box may not fit and is moved to the next page.

I agree with George, floating frames are better, they stay where they are.  Set text wrap on those floating boxes so that they don't overlap text.

P.

S
Summayah5FC7Author
Inspiring
May 18, 2022

Floating frames that are anchored?

Geоrge
GeоrgeCorrect answer
Legend
May 18, 2022

Yep, only frame without text. But paragraph style with shading feature is better.



Remember, never say you can't do something in InDesign, it's always just a question of finding the right workaround to get the job done. © David Blatner
    Geоrge
    Geоrge
    Legend
    May 18, 2022

    Why don't you use it some frame as anchor? This is wrong workflow.



    What about paragraph shading for the orange summary?



    https://youtu.be/wo7PlTVlq_I



    https://www.adobepress.com/articles/article.asp?p=2418567







    Remember, never say you can't do something in InDesign, it's always just a question of finding the right workaround to get the job done. © David Blatner
    S
    Summayah5FC7Author
    Inspiring
    May 18, 2022

    Thank you.

    It's the rounded corners and the heading style
