How to create action to use the RULER tool

Creating an action to use the Ruler tool in Photoshop can be quite handy, especially if you find yourself frequently needing to measure distances or angles in your designs. Here's how you can create an action for it:

1. **Open Photoshop:**

   Open Adobe Photoshop on your computer.

2. **Open an Image:**

   Open the image on which you want to use the Ruler tool.

3. **Open the Actions Panel:**

   Go to `Window` > `Actions` to open the Actions panel if it's not already open.

4. **Create a New Action:**

   In the Actions panel, click on the "Create new action" icon at the bottom. It looks like a sheet of paper.

Creating an action to use the Ruler tool in Photoshop can be quite handy, especially if you find yourself frequently needing to measure distances or angles in your designs. Here's how you can create an action for it:

1. Open Photoshop: Open Adobe Photoshop on your computer.

2. Open an Image: Open the image on which you want to use the Ruler tool.

3. Open the Actions Panel: Go to Window > Actions to open the Actions panel if it's not already open.

4. Create a New Action: In the Actions panel, click on the "Create new action" icon at the bottom. It looks like a sheet of paper.

5. Name the Action: Name your action something like "Measure with Ruler" and choose a set for it. Then click 'Record'.

6. Use the Ruler Tool: Select the Ruler tool from the toolbar. It's nested under the Eyedropper tool. Alternatively, you can press "I" on your keyboard to select it.

7. Measure: Click and drag to measure distances or angles on your image.

8. Stop Recording: Once you're done with the measurements, go back to the Actions panel and click the "Stop" button (the square icon) at the bottom of the panel.

9. Testing: Before finalizing, it's a good idea to test your action to make sure it works as expected.

10. Assign a Function Key (Optional): You can also assign a function key to the action for quick access. To do this, select the action, click on the "Actions" menu icon (three horizontal lines at the top-right corner of the Actions panel), then select "Insert Menu Item...". Choose a function key and click "OK".

11. Save your Action: Once you're satisfied with your action, make sure to save it. Actions are saved automatically when you save your PSD file, but you can also save them separately by clicking on the "Save Actions" option in the Actions panel menu.

Now, whenever you need to measure something with the Ruler tool, you can simply run this action instead of manually selecting the tool and measuring each time.

    Once you're satisfied with your action, make sure to save it. Actions are saved automatically when you save your PSD file, but you can also save them separately by clicking on the "Save Actions" option in the Actions panel menu.

Now, whenever you need to measure something with the Ruler tool, you can simply run this action instead of manually selecting the tool and measuring each time.

Visit My Website

@Marc VanZ

The crop tool can be called via a tool preset in an action, and if you use a modal control to make the crop tool step interactive, you can press the "straighten" button.

This might do what you want!

Actions can't select tools directly, but they can indirectly select a tool by selecting a named tool preset.

Scripts can directly select a tool.
