RoboHelp 2019 New UI-Output Header Title Font Size

  • October 1, 2020
  • 17 replies
  • 815 views

Is there a way to change the font size of the header when generating Responsive HTML5?



I've looked at the skin but I am unable to find something that changes the font size of the header.



I want to change it because it's wrapping on the output and the second line is squished.



Thank you.

    This topic has been closed for replies.

    17 replies

    Community Expert
    October 5, 2020

    "I am in the process of creating a new CSS but I have to enter everyting for it so it's taking some time. "



    You don't need to enter every style in the custom css, just the few things you want to override. Everything else will come from the skin css file.

    Peter Grainge
    Community Expert
    Community Expert
    October 5, 2020

    More functionality and bug fixes. See the RoboHelp Tour on my site.



    Whether or not you need the features only you can decide.



    Use the menu (bottom right) to mark the Best Answer or Highlight particularly useful replies. Found the answer elsewhere? Share it here.
    chelluvsGod
    Inspiring
    October 5, 2020

    Can you quickly give reasons for going to version 2020? What are the benefits of that version?

    Peter Grainge
    Community Expert
    Community Expert
    October 5, 2020

    I see no reason to hold back. If in doubt, zip up a copy of the project before upgrading.



    Use the menu (bottom right) to mark the Best Answer or Highlight particularly useful replies. Found the answer elsewhere? Share it here.
    chelluvsGod
    Inspiring
    October 5, 2020

    I am in the process of creating a new CSS but I have to enter everyting for it so it's taking some time.



    In the meantime, should I continue using RoboHelp 2019 or would it be prudent to move to version 2020?

    Peter Grainge
    Community Expert
    Community Expert
    October 3, 2020

    "This version of RoboHelp is simply impossible to use if you don't have a programmer background."



    Sorry but I disagree, let me explain.



    In the Classic versions prior to the new UI there were ways of editing things that could not be customised through the skin editor. I wouldn't argue that what you want to do should be in the UI but that's another matter. The problem was that when Adobe had to make technical changes behind the scenes, it overwrote those behind the scenes customisations. They all had to be repeated.



    In the new UI versions of the skins, the technical stuff is separated from what you see so that any customisation has to be applied through the skin editor. That way Adobe can add functionality or fix issues in an update without affecting any customisation applied.



    The idea is that those users who have technical knowledge or access to it can run a script post generation or add some user assets. However, for most purposes it is not expected that this is necessary.



    Going forward frameless skins are the ones getting attention and, as Amber has pointed out they have more customisation options.



    Notwithstanding all the above, submit a bug report as the Azure Blue skin remains popular. Please follow this link to report bugs. https://tracker.adobe.com



    Post the link to your bug report in this thread and others can vote for it. The more people who do so, the higher it gets prioritised.



    Use the menu (bottom right) to mark the Best Answer or Highlight particularly useful replies. Found the answer elsewhere? Share it here.
    Community Expert
    October 3, 2020

    Yep, RH2019 New UI is a very weird blend of super simplified and super advanced. I don't think Adobe had accurate user stories when they designed it.



    They haven't actually provided any access to the stylesheet for responsive outputs, so that's why a custom one is necessary.



    In that screenshot where you have the title selected, in the right-hand panel you need to copy the name of that first style (from body to div.title).



    Then open your custom stylesheet and switch to code view using the </> icon.



    Paste the style name in, then type { font-size: xxx;}. Replace xxx with whatever you need the font size to be.



    To add the stylesheet to your skin, when you get to the screen with all the icons, that's just Windows file explorer, so browse to your assets folder and select the css file you created.



    Generate your output and check the font size is correct. If you can't see any difference you might need to make another change to the style, but I'm hoping not. Post back if you can't see any difference and I'll explain.



    Then to make sure the font size is what you need on a tablet, resize the browser window to approximately an iPad size and you'll see the layout change. Repeat the Inspect step and the steps above to add the table style to your custom stylesheet. After you add the style to the stylesheet, I think you'll need to remove the stylesheet from the skin and re-add it - another user reported that changes to this custom css don't show without this step.



    Then you need to repeat once more for a mobile phone size.



    I can also recommend working through the W3 Schools CSS tutorial. The Try It Yourself feature is really handy. https://www.w3schools.com/css/



    On another note, I think Frameless skins have more of the stylesheet available in the Robohelp interface, so you could investigate changing output type. It still has weird omissions so you might have to look at custom css depending on what you need, but probably not as frequently.

    chelluvsGod
    Inspiring
    October 2, 2020

    Okay, yes, that is the correct tag.

    But:

    1. Why do I need to create a custom CSS, why can't I amend the one I'm using?

    2. I don't understand how creating a custom CSS will affect the font size on the output for the header.

    This version of RoboHelp is simply impossible to use if you don't have a programmer background.

    Jeff_Coatsworth
    Community Expert
    Community Expert
    October 2, 2020

    Ok, so that looks like it's that div.title part in layout.css that has the line-height at 100%, font-size at 1.625em, etc. Try editing that layout.css in the output to see if changing those values has the effect that you want to achieve. That will confirm that it's the correct tag you need to manipulate in your custom version of CSS that @Amebr was talking about.

    chelluvsGod
    Inspiring
    October 2, 2020

    Oh. Sorry, I guess I was looking at the incorrect thing. Here it is expanded:
