Creating bleeds in an imported pdf document?

  • February 5, 2019
  • 4 replies
  • 2059 views

So we have pdf documents that have multiple pages that we've imported into indesign using multiple page script.

I haven't been able to figure out to export the document with bleeds that are usable for print. When import the pdf's, it imports the whole page as a single object, so I can't transform anything without it messing up the text, etc.

Any ideas?

I've included an image of how it exports.

This topic has been closed for replies.
Correct answer John Mensinger

Thanks! Centering it made it so much easier!

I tried to export it but no matter the scale or percentage i put it in - it still cuts the bleed right at the crop mark. Am I exporting it wrong, or is there something I need to do to recognize the expanded object?


Before you try it again, go to File > Document Setup > Bleed and Slug > Bleed and enter a bleed amount. an eighth-inch or 3 mm should be enough.

Then, when you export again, go to the Marks and Bleeds page of the Export PDF dialog and tick the Use Document Bleed Settings checkbox.

4 replies

Colin Flashman
Braniac
February 6, 2019

There is also this really cool script from Marc Autret from Indiscripts that could help you directly in InDesign too: Indiscripts :: FillBleed | Fix Image Frames so they Meet the Bleed Edge [Update]

If the answer wasn't in my post, perhaps it might be on my blog at colecandoo!
Colin Flashman
Braniac
February 6, 2019

I agree with Luke's answers (either get the client to supply it correctly to your specs, or use Enfocus Pitstop to fix it).

The latest version of Enfocus Pitstop has an action within the action lists that does a really good job and would work in your example.

Before:

After:

If you don't have the Enfocus Pitstop plug-in, you could try using a preflight within Adobe Acrobat's print production tools. There are two custom fixups that can add bleed, but when I tested them in the above example, both did not have the desired results. I think it is meant to work with raster images, and not vector graphics.

If the answer wasn't in my post, perhaps it might be on my blog at colecandoo!
Luke Jennings
Inspiring
February 5, 2019

In addition to the good information above, I would ask for a new PDF, correctly exported with bleed, although in my experience the response is likely to be "can you please fix it"?

If you have PitStop, you can create bleed where none exists, or if the PDF was created in Illustrator, you may be able to safely open it and fix the bleed, if not, then John's suggestions are your best option.

Edit, you can also place a 2nd instance of the PDF on the page, slightly enlarged and cropped, to add bleed.

John Mensinger
Inspiring
February 5, 2019

There's no way to manufacture bleed from the placed PDF (images) which have none. I don't know if the example you showed is typical of all the pages, but to add bleed to the example:

  • Determine what color green that is
  • Make new elements (simple rectangles in this case) filled with that green and extend them into the bleed area

It would be great if the green is a known spot color and a reliable match meant you could put the new bleed-extended elements behind/under the placed PDF. But if that's not the case, a near-match could force you to put the new elements in front of/above the placed PDF, and you'll also have to replicate the numbering.

jamespublishing
Participating Frequently
February 5, 2019

That's what I thought.

I had another idea of being able to scale the object to 101% - then "transform again" all the other pages.

The problem is I was unable to figure out how to center all the objects.

Would that work?

John Mensinger
John MensingerCorrect answer
Inspiring
February 5, 2019

Thanks! Centering it made it so much easier!

I tried to export it but no matter the scale or percentage i put it in - it still cuts the bleed right at the crop mark. Am I exporting it wrong, or is there something I need to do to recognize the expanded object?


Before you try it again, go to File > Document Setup > Bleed and Slug > Bleed and enter a bleed amount. an eighth-inch or 3 mm should be enough.

Then, when you export again, go to the Marks and Bleeds page of the Export PDF dialog and tick the Use Document Bleed Settings checkbox.
