How to add anchor points to paths with js script

@Bryce29110882cdze, this most certainly will not work and smells a bit like it was ChaptGPT generated (same as your other posts here and here). The Illustrator API doesn't allow you to access anchor points like `sel.anchor[0]`, and using `sel.pathPoints.add()` appends a point to the end of the path, it doesn't insert it along the path as I mentioned above. You must recreate the original path with the new point as @femkeblanco does in his code.

This is a quick attempt intended for non-curved lines. To Use: (1) select one point (with the white arrow tool); (2) to add a point after, use a positive number; to add a point before, use a negative number. (The script will fail if you try to add before the first point or after the last point.)

var input = prompt("", "30");
var before = [];
var after = [];
var swap = false;
var j;

var path1 = app.activeDocument.selection[0];
var points = path1.pathPoints;
for (var i = 0; i < points.length; i++) {
    if (points[i].selected == PathPointSelection.ANCHORPOINT) {
        swap = true;
        j = i;
        continue;
    }
    if (swap) {
        after.push([points[i].anchor[0], points[i].anchor[1]]);
    } else {
        before.push([points[i].anchor[0], points[i].anchor[1]]);
    }
}

var addedPoint, array;
if (input > 0) {
    addedPoint = getAddedPoint(points[j], points[j + 1], input);
    array = before.concat(
        [[points[j].anchor[0], points[j].anchor[1]], addedPoint])
} else {
    addedPoint = getAddedPoint(points[j], points[j - 1], -input);
    array = before.concat(
        [addedPoint, [points[j].anchor[0], points[j].anchor[1]]])
}
array = array.concat(after);

var path2 = app.activeDocument.pathItems.add();
path2.setEntirePath(array);
path2.selected = true;
path1.remove();

function getAddedPoint(p1, p2, h) {
    var x1 = p1.anchor[0];
    var y1 = p1.anchor[1];
    var x2 = p2.anchor[0];
    var y2 = p2.anchor[1];
    var dx = x2 - x1;
    var dy = y2 - y1;
    var a = Math.atan2(dy, dx)
    dx = Math.cos(a) * h;
    dy = Math.sin(a) * h;
    return [x1 + dx, y1 + dy];
}

Yes, it's possible. The only catch is that if you want to add a point between already existing points on the path you essentially have to recreate the path via your script up until the new point. If you just append a point to your path like described in the API docs (see here), it will be added to the end of the path.

Below is some EXPERIMENTAL code I was playing with a while back for splicing paths. PLEASE NOTE, if your path has any curves you would need to calculate updated handle points (left/right direction) which is doable using an algorithm like De Casteljau's algorithm.

Hopefully, you can get what you need from this. Cheers!

function PathPointPlus(obj) {
  this.self = obj;
  for (prop in obj) {
    try {
      this[prop] = obj[prop];
    } catch (e) {
      this[prop] = e;
    }
  }
  // allow user to specify only an anchor point when creating custom points
  if (!this.hasOwnProperty("leftDirection")) this.leftDirection = this.anchor;
  if (!this.hasOwnProperty("rightDirection")) this.rightDirection = this.anchor;
  if (!this.hasOwnProperty("pointType")) this.pointType = PointType.CORNER;
}

PathPointPlus.prototype = {
  addToPath: function (parentPath, idx) {
    // add to end of path if index not specified
    idx = idx !== undefined ? idx : parentPath.pathPoints.length;
    // prompt for index for example purposes
    // idx = prompt("What index?", idx);
    // validate provided index
    if (idx < 0 || idx > parentPath.pathPoints.length) {
      alert(
        "Invalid insertion index (`idx`).\n0 <= idx <= " + parentPath.pathPoints.length
      );
      return;
    }
    // remove all points after idx
    var removedPoints = [];
    if (idx < parentPath.pathPoints.length) {
      for (var i = parentPath.pathPoints.length - 1; i >= idx; i--) {
        removedPoints.push(new PathPointPlus(parentPath.pathPoints[i]));
        if (i == 0) {
          parentPath.pathPoints[i].anchor = this.anchor;
          parentPath.pathPoints[i].leftDirection = this.rightDirection;
          parentPath.pathPoints[i].rightDirection = this.leftDirection;
          parentPath.pathPoints[i].pointType = this.pointType;
        } else {
          parentPath.pathPoints[i].remove();
        }
      }
    }
    // add the points back
    if (idx > 0) removedPoints.push(this);
    // add the new point plus the removed points
    var newPoint;
    for (var i = removedPoints.length - 1; i >= 0; i--) {
      newPoint = parentPath.pathPoints.add();
      newPoint.anchor = removedPoints[i].anchor;
      if (removedPoints[i].hasOwnProperty("leftDirection"))
        newPoint.leftDirection = removedPoints[i].rightDirection;
      if (removedPoints[i].hasOwnProperty("rightDirection"))
        newPoint.rightDirection = removedPoints[i].leftDirection;
      if (removedPoints[i].hasOwnProperty("pointType"))
        newPoint.pointType = removedPoints[i].pointType;
    }
  },
};

function PathItemPlus(obj) {
  this.self = obj;
  for (prop in obj) {
    try {
      this[prop] = obj[prop];
    } catch (e) {
      this[prop] = e;
    }
  }
}

PathItemPlus.prototype = {
  /**
   * The splice() method changes the PathPoints of a PathItem by removing
   * or replacing existing PathPoints and/or adding new PathPoints in place.
   *
   * splice(start, deleteCount, item1, item2, itemN)
   *
   * @9397041   {Number}    start       Zero-based index at which to start replacing or removing PathPoints.
   * @9397041   {Number}    deleteCount An integer indicating the number of PathPoints in the PathItem to remove from start.
   * @9397041   {PathPoint} item...     The PathPoints elements to add to the PathItem, beginning from start.
   * @Returns {Array}                 An array containing the deleted PathPoints.
   */
  splice: function (start, deleteCount) {
    var arr = [];
    var resultArr = [];

    start = start !== undefined ? Number(start) : 0;

    // delete entire path if start = 0
    if (start === 0 && deleteCount === undefined) {
      for (var i = 0; i < this.pathPoints.length; i++)
        resultArr.push(new PathPointPlus(this.pathPoints[i]));
      this.self.remove();
      return resultArr;
    }

    // append items to end if start if > pathPoints
    if (start > this.pathPoints.length) {
      start = this.pathPoints.length;
      end = this.pathPoints.length;
      deleteCount = 0;
    }

    // if start is a negative number
    if (start < -this.pathPoints.length) {
      start = 0;
    } else if (start < 0) {
      start = start + this.pathPoints.length;
    }

    deleteCount = deleteCount !== undefined ? Number(deleteCount) : 0;
    if (deleteCount >= this.pathPoints.length - start) {
      deleteCount = this.pathPoints.length - start;
    } else if (deleteCount === undefined) {
      deleteCount = 0;
    }

    // grab all items to splice (if any)
    var items = [];
    for (var i = 2; i < arguments.length; i++) items.push(arguments[i]);

    var stop = this.pathPoints.length;

    // if deleteCount is defined
    if (deleteCount) {
      // we add it to start. This gives us the index we will stop in the data array.
      stop = start + deleteCount;
      // if deleteCount is negative, we splice no array
      if (deleteCount < 0) stop = 0;
    }

    // cut out the deleted points
    for (var i = start; i < stop; i++) {
      resultArr.push(new PathPointPlus(this.pathPoints[i]));
    }

    // if deleteCount is defined but items is empty
    if (deleteCount && items.length <= 0) {
      for (var i = 0; i < this.pathPoints.length; i++) {
        if (i === start) {
          i = stop;
        } else {
          arr.push(new PathPointPlus(this.pathPoints[i]));
        }
      }
    }

    // if there is something in the items array
    if (items.length > 0) {
      for (var i = 0; i < this.pathPoints.length; i++) {
        if (i === start && arr.length < start + items.length) {
          arr = arr.concat(items);
          i = deleteCount > 0 ? stop : i - 1;
        } else {
          arr.push(new PathPointPlus(this.pathPoints[i]));
        }
      }
    }

    // actually delete the points from the path
    if (deleteCount > 0) {
      for (var i = 0; i < resultArr.length; i++) {
        if (resultArr[i].self.hasOwnProperty("remove")) resultArr[i].self.remove();
      }
    }

    // remove all points (except first)
    for (var i = 1; i < this.pathPoints.length; i++) {
      this.pathPoints[i].remove();
    }

    // add the updated points
    if (arr) {
      for (var i = start; i < arr.length; i++) {
        if (i === 0) {
          this.pathPoints[i].anchor = arr[i].anchor;
          if (arr[i].hasOwnProperty("leftDirection"))
            this.pathPoints[i].leftDirection = arr[i].leftDirection;
          if (arr[i].hasOwnProperty("rightDirection"))
            this.pathPoints[i].rightDirection = arr[i].rightDirection;
          if (arr[i].hasOwnProperty("pointType"))
            this.pathPoints[i].pointType = arr[i].pointType;
        } else {
          arr[i].addToPath(this, this.pathPoints.length);
        }
      }
    }

    return resultArr;
  },
};
