Align Objects on Path in 4 simple steps

Forum|Forum|1 year ago
October 14, 2024
18 replies
7749 views

Unleash your creativity with 'Objects on Path' in Illustrator 2025 version 29.0 - easily attach, arrange, and move objects along any path, giving designers new ways to create with speed and precision.

Try it yourself

Follow along with a sample file to learn how to use the Objects on Path tool in a few simple steps.

Note:

Objects on Path is only available for Illustrator version 29.0 or later. Update the app now!

Check out our tutorial for a first-hand look at it in action!

A special thanks to Saurav Agrawal (Product Manager- Adobe Illustrator), for sharing this video!

Unlock new creative possibilities with 'Objects on Path' – effortlessly align, arrange, and move objects with precision.

Let’s get started with Objects on Path:

Step 1: Select the objects you want to attach to a path.

Step 2: Invoke the "Objects on Path" Tool from Tool Panel or Object Menu or the Align Panel or Contextual Menu

Step 3: Select the Target Path you want your objects to align with. The objects will automatically attach to the path.

Step 4: Adjust Properties.

Spacing: Adjust the space between the objects along the path.

Rotation: Rotate objects to follow the path’s curvature.

Movement: Move objects along the path.

Orientation Control: Change Point of Attachment where each object attaches to the path using 9 point widget in Properties Panel.

Objects are now arranged in visual order, based on left-to-right or top-to-bottom orientation.

Extended possibilities with this feature:

Modify Path: After attaching objects, edit the path and watch the objects move and rearrange themselves automatically.
Shuffle Objects: Use the shuffle widget to swap positions of objects along the path.
Detach Objects: Detach one or more objects from the path without removing the path itself.
Attach more objects: In the Layers panel, drag objects into the Objects on Path group to automatically attach them to the end of the path.
Create a copy of Attached object: Also, in isolation mode, copy and paste objects into the group, and they will attach to the path automatically.

Expand the Objects on Path group: Use Expand to convert the Objects on Path group into a regular group.

Note: The order of the objects on the path won't change if you rearrange them in the Objects on Path group in the Layers panel.

This update makes working with paths much more versatile and user-friendly. Make sure to explore the new capabilities, and share your feedback to help improve the feature further! For more details & FAQs about this new feature, please click here.

We’d love to hear from you!

Try out the new "Objects on Path" feature and let us know your thoughts. Feel free to reach out if you have any questions or need more tips!

If this was helpful, please click the Upvote icon in the top left corner of this post. Your feedback helps us improve the experience. Thank you!

Have questions? Click 'Reply' below to ask.

Click 'Follow' below to bookmark this post for easy reference.

Z

zille_2346

New Participant

Valuable info.

Connections that count

S

susanr27157184

Known Participant

It would be helpful if you could click on the path in the exact location we want the starting path to be for the objects, especially for the closed paths.

@mj

Braniac

Great idea!

S

StephenPhillipsUK

New Participant

Great edition to Illsutrator and a very useful feature. May I suggest a few extra options to improve it?

Multiply objects - to add copies
Do not rotate objects along path - to keep the original orientation
Randomise spacing - so objects can be more naturally or randomly placed e.g. trees
Randomise scale - so objects can be randomised by width or height
Nudge - a helper to adjust the position of any object

A

Anubhav M

Community Manager

Hello @StephenPhillipsUK,

These are great ideas. Would you mind creating a UserVoice for this feature request (https://adobe.ly/3AxnLL4) and adding your comments there? Doing this will help us prioritize this request, and you will be notified of any updates.

Feel free to reach out if you have more questions or need assistance. We'd be happy to help.

Thanks,

Anubhav

S

serv_7223

New Participant

There is not needet Uuservoice.

These options are must have.

Now I tried "Objects on Path" and I dont want rotation of objects in this case. For now it is useless for me

@mj

Braniac

Proper!

M

motodesigns

New Participant

Love this new tool! Is there a way to distribute objects spacing manually? I want to create space between words on the path, but everytime I move a letter (object) it snaps right back to the spacing with the other objects.

Monika Gause

Braniac

Love this new tool! Is there a way to distribute objects spacing manually? I want to create space between words on the path, but everytime I move a letter (object) it snaps right back to the spacing with the other objects.

By @motodesigns

Is this what you want? If so, please upvote: https://illustrator.uservoice.com/forums/333657/suggestions/48987899

K

katherineboroski

Participating Frequently

I would LOVE this enhancemet as well. And yes, that suggestion above on UserVoice is exactly what I need as well. Unfortunately, I have never been able to vote, comment or post on that site. The only method of logging in that works for me is to sign in with google. I wanted to try and create a new account, but that doesn't work for me either. I've tried in different browsers, on different devices. No clue what the deal is! So, if anyone has any suggestions, I'm all ears.
