How do I export objects that are not in the artboard? (ex. dieline)

  • July 7, 2017
  • 3 replies
  • 2849 views

In this example, the six gray lines at the top are outside of the artboard, yet they show up when this was exported.

    This topic has been closed for replies.
    Correct answer Jeff Witchel, ACI

    Oh, set up a Slug area.

    1. File > Document Setup.
    2. Reveal Bleeds and Slug if it's not showing.
    3. Enter amounts for Slug Area that are big enough to contain your Die Lines.
    4. Click OK to apply.

    When you Export to PDF, make sure to check "Include Slug Area" in the Marks and Bleeds section of the dialog window.

    That will include your entire Slug Area in your PDF.

    3 replies

    Jongware
    Jongware
    Community Expert
    July 7, 2017

    Are you sure your question title and problem description refer to the same thing?

    All objects that cross the page are exported. If these gray lines indeed cross the page from left to right, then they are part of the page and should be exported. If you don't want them, delete them or set to "not printing".

    As for your title (and definitely not the image): if you need die lines outside of the page to export, add extra slug (not "bleed"! That is for a different purpose.) around the page, within which you place those lines. Make sure the "Use document slug" checkbox is on when exporting to PDF.

    K
    kerrys96413853Author
    Participating Frequently
    July 7, 2017

    I now realize the first image I posted is a little confusing.

    That was a screenshot of a PDF I didn't export.

    I made updates to the original document and want to export it just like the original PDF.

    However, when I export, it comes out different. (Without the gray lines)

    The left image is what I exported. The right image is how I need it to be.

    Preferably without using slugs.


    Thanks,

    Luke Jennings
    Luke Jennings
    Inspiring
    July 10, 2017

    The difference between the two PDFs is the one on the right was exported with a larger crop mark offset, possibly .5". By using a larger offset, the PDF media box size was increased (not the trim size) and the extra lines were revealed. The crop mark offset should be at least as large as the bleed amount. BTW, in Acrobat you can view the PDF Art, Trim & Bleed boxes by going to Preferences> Page Display> Show art, trim & bleed boxes.

    Jeff Witchel, ACI
    Jeff Witchel, ACI
    Community Expert
    July 7, 2017

    If I'm understanding what you're asking, the six lines are part are part of a Die Line and you don't want them to be exported or printed. Place the Die Line in a separate Layer in the Layers panel and click on the Visibility Eye next to the Layer to turn off the visibility of that Layer and the Die Line won't export or print.

      K
      kerrys96413853Author
      Participating Frequently
      July 7, 2017

      Hi Jeff, I actually do want them to show up when I export  to PDF.

      The lines are not in the page as you can see in the attached image.

      The the previous image is an example i want to replicate. Hope this makes better sense.


      Thanks,

      Jeff Witchel, ACI
      Jeff Witchel, ACICorrect answer
      Community Expert
      July 7, 2017

      Oh, set up a Slug area.

      1. File > Document Setup.
      2. Reveal Bleeds and Slug if it's not showing.
      3. Enter amounts for Slug Area that are big enough to contain your Die Lines.
      4. Click OK to apply.

      When you Export to PDF, make sure to check "Include Slug Area" in the Marks and Bleeds section of the dialog window.

      That will include your entire Slug Area in your PDF.

      AnneMarie Concepcion
      AnneMarie Concepcion
      Community Expert
      July 7, 2017

      Artboard? Do you mean Illustrator? This is the InDesign forum.

      Or are you just referring to the InDesign page as an artboard.

      AM

      K
      kerrys96413853Author
      Participating Frequently
      July 7, 2017

      Yes sorry, I meant Indesign page.

      Bill Silbert
      Bill Silbert
      Community Expert
      July 7, 2017

      What do you mean when you say "exported"? To print? To pdf? And are you referring to the grey lines on the left and right  of the art? Do you want the art exported with the crop marks which appear to have been drawn manually? InDesign allows you to use automatic crops which are much more accurate than any you might draw manually. Please give some more information.
