Links to topics at the folder level unresponsive in CHM

  • June 1, 2020
  • 4 replies
  • 432 views

RoboHelp 2019 New UI



I have set up topic links to folders in my project TOC and when output to ResponsiveHTML5, the links work fine.  But, when I produce a CHM of the same TOC, two of the folders are unresponsive and do not show the topic. All of the linked topics just consist of a single JPG.  I don't see any difference in the topics such that only 2 would not display (see image).





    This topic has been closed for replies.
    Correct answer Peter Grainge

    I have since learned that the & in the file name causing the problem is a bug that will be fixed in an update. Nonetheless, I still recommend sticking with alphnumeric characters, hyphens and underscores in file names generally.



    4 replies

    Peter Grainge
    Community Expert
    Peter GraingeCommunity ExpertCorrect answer
    Community Expert
    June 2, 2020

    I have since learned that the & in the file name causing the problem is a bug that will be fixed in an update. Nonetheless, I still recommend sticking with alphnumeric characters, hyphens and underscores in file names generally.



    Help others by clicking Correct Answer if the question is answered. Found the answer elsewhere? Share it here. "Upvote" is for useful posts.
    Peter Grainge
    Community Expert
    Peter GraingeCommunity Expert
    Community Expert
    June 1, 2020

    The CHM compiler was last updated by Microsoft in 2004. In those days only alphanumeric characters and a few others such as underscores were permitted, so no surprise with that. Generally I stick with those characters as it is always safer.



    Well done on the detective work.



    Help others by clicking Correct Answer if the question is answered. Found the answer elsewhere? Share it here. "Upvote" is for useful posts.
    G
    GLNT1Author
    Inspiring
    June 1, 2020

    After futher troubleshooting, I found the issue.  The topics that were not showing had JPGs that had an "&" in the title.  It looks like the CHM has a problem with those, but not HTML5.

      G
      GLNT1Author
      Inspiring
      June 1, 2020

      Upon checking the two "nondisplayable" HTML files in explorer, I get this message. So, I guess this is not a RoboHelp issue. I don't remember doing anything different with these images.
